8.3. Disassembly Procedure
No. Item Fig Removal
1 Lens Hood (Fig. D1) Lens Hood
2 Side Case (R) Unit (Fig. D2) 1 Screw (A)
3 Screws (B)
4 Screws (C)
2 Screws (D)
1 Screw (E)
R Cover
(Fig. D3) FP6502 (Flex)
Side Case (R) Unit
3 Side Case (L) Unit (Fig. D4) 2 Screws (F)
6 Screws (G)
1 Screw (H)
Side Case (L) Unit
4 HDD Unit. (Fig. D5) 1 Screw (I)
HDD Unit
5 Front Case Unit (Fig. D6) 3 Screws (J)
Sensor Window Unit
(Fig. D7) FP6003 (Flex)
Front Case Unit
6 Top Case Unit (Fig. D8) FP6401 (Flex)
P6401 (Connector)
FP6402 (Flex)
2 Screws (K)
1 Screw (L)
1 Screw (M)
3 Locking tabs
Top Case Unit
7 Battery Case Unit (Fig. D9) PS6001 (Flex)
1 Screw (N)
1 Screw (O)
Battery Case Unit
8 Lens Unit (Fig. D10) PS6003 (Flex)
PS6002 (Flex)
1 Screw (P)
Lens Unit
9 Lens Plate Unit (Fig. D11) FP6401 (Connector)
1 Screw (Q)
Lens Plate Unit
10 Main P.C.B. (Fig. D12) 1 Screw (R)
2 Locking tabs
PS6004 (Flex)
Main P.C.B.
11 Sub P.C.B. (Fig. D13) 4 Screws (S)
Main Frame
Bottom Frame
Main/Sub Flex
Sub P.C.B.
12 Flash P.C.B. (Fig. D14) 1 Screw (T)
Lens Plate
(Fig. D15) Solder (3 points)
2 Locking tabs
Capacitor Cover Unit
Flash P.C.B.
13 Side (R) P.C.B. (Fig. D16) 2 Screws (U)
5 Screws (V)
FP601 (Flex)
Side (R) P.C.B.
14 LCD Unit (Fig. D17) Hinge Plate
2 Ribs
Operation knob
SR SW knob
Flex
LCD Unit
15 Monitor P.C.B. (Fig. D18) 2 Screws (W)
6 Locking tabs
(Fig. D19) FP901 (Flex)
LCD Hinge Unit
LCD Earth Plate
FP902 (Flex)
3 Locking tabs
Monitor P.C.B.
16 LCD (Fig. D20) Reflection Sheet
Light Panel
Diffusion Sheet
Prism Sheet B
Prism Sheet A
Lens Holder
LCD Shield Sheet
LCD Bottom Case
LCD
17 Barrier Motor Unit (Fig. D21) 3 Screws (X)
Earth Plate
Barrier Select knob
Front Cover
Cushion
Barrier Motor Unit
18 HDD (Fig. D22) 2 Screws (Y)
4 Ribs
HDD Cover A
HDD Cover B
Cushion A
Cushion B
HDD
19 Battery Spring
Battery knob
(Fig. D23) 2 Screws (Z)
CCD Shield Case
1 Screw (a)
Battery Release Holder
Battery Spring
Battery knob
20 Power FPC (Fig. D24) 1 Screw (b)
Rear Frame
2 Locking tabs
Power FPC
21 SD Card Unit (Fig. D25) 1 Screw (c)
Rear Earth Angle
1 Locking tab
(Fig. D26) 1 Locking tab
Battery Case
SD Card Unit
22 Mic P.C.B. (Fig. D27) Mic FPC
1 Screw (d)
FP4801 (Flex)
Mic P.C.B.
23 Mic (Fig. D28) 2 Screws (e)
Mic Angle
3 Locking tabs
Sheet
Mic Net
Mic
24 Rear Operation Unit (Fig. D29) 1 Screw (f)
Rear Operation Unit
25 Speaker (Fig. D30) 3 Screws (g)
(Fig. D31) Tape
Top Frame
Top Cover
Top Piece
Speaker
