Sony HDC-HS9P - S2. Voltage Chart; S2.1. Flash P.C.B; S2.3. MIC P.C.B; S2.4. Monitor P.C.B

S-2
S2. Voltage Chart
S2.1. Flash P.C.B.
Note) Indicated voltage values are the standard values for the unit measured by the DC electronic circuit tester (high-impedance) with the chassis taken as standard.
Therefore, there may exist some errors in the voltage values, depending on the internal impedance of the DC circuit tester.
REF No. PIN No. POWER ON
Q7001 E 0
Q7001 C 0
Q7001 B 1
Q7002 E 0
Q7002 C 1
Q7002 B 0
Q7003 E 0
Q7003 C 2.6
Q7003 B 0.8
QR6402 E 3.8
QR6402 C 3.6
QR6402 B 0
QR6403 E 3.8
QR6403 C 0
QR6403 B 4.1
QR7001 E 0
QR7001 C 2.3
QR7001 B 0
QR7008 E 0
QR7008 C 1
QR7008 B 0
S2.2. Side R P.C.B.
REF No. PIN No. POWER ON
IC601 1 1.8
IC601 2 0
IC601 3 2.5
IC601 4 2.7
IC601 5 0
IC601 6 0
IC601 7 1.4
IC601 8 2.7
IC601 9 3
IC601 10 0.2
IC601 11 0.1
IC601 12 3.2
IC601 13 3.5
IC601 14 3.2
IC601 15 0
IC601 16 0
IC601 17 1.4
IC601 18 1.3
IC601 19 3.2
IC601 20 3.2
IC601 21 3.1
IC601 22 0
IC601 23 0
IC601 24 6
IC601 25 0
IC601 26 0
IC601 27 3.3
IC601 28 3.3
IC601 29 3.3
IC601 30 3.3
IC601 31 6
IC601 32 6.6
IC601 33 6
IC601 34 0.3
IC601 35 5.6
IC601 36 6.3
IC601 37 0
IC601 38 2.7
IC601 39 3.5
IC601 40 3.5
IC601 41 6.7
IC601 42 2
IC601 43 1.4
IC601 44 1
IC601 45 0.9
IC601 46 0.8
IC601 47 0.3
IC601 48 0
IC601 49 0.2
IC601 50 0.2
IC601 51 0.2
IC601 52 0
IC601 53 0
IC601 54 0.2
IC601 55 0
IC601 56 2.7
IC601 57 2.6
IC601 58 0
IC601 59 0
IC601 60 0
IC601 61 3.2
IC601 62 0
IC601 63 0
IC601 64 1.2
IC604 1 6
IC604 2 0
REF No.
PIN No. POWER ON
IC604 3 0
IC604 4 3.3
IC604 5 6
S2.3. Mic P.C.B.
REF No. PIN No. POWER ON
IC4801 1 3.3
IC4801 2 3.3
IC4801 3 2.8
IC4801 4 0
IC4801 5 2.8
IC4801 6 3.3
IC4801 7 2.9
IC4801 8 6.5
IC4803 1 2.8
IC4803 2 2.8
IC4803 3 2.8
IC4803 4 0
IC4803 5 2.8
IC4803 6 2.6
IC4803 7 2.6
IC4803 8 6.5
Q4801 E 5.7
Q4801 C 6.5
Q4801 B 6.5
S2.4. Monitor P.C.B.
REF No. PIN No. POWER ON
Q901 E 0.9
Q901 C 2.3
Q901 B 1.9
Q902 E 0.9
Q902 C 2.3
Q902 B 1.9
Q903 E 0.9
Q903 C 2.3
Q903 B 1.9
Q905 E 0
Q905 C -6.2
Q905 B 0
Q910 E 1.9
Q910 C 0
Q910 B 1
