Sony HDC-HS9P - Page 70

HDC-HS9E-S,EB-S,EG-S,EE-S,EP-S,GC-S,GN-S,GK-S,SG-S,P-S,PC-S,PL-S voL.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
201 VXQ1548 PRISM UNIT 1
201-1 VEP22388A CCD FPC UNIT 1
203 VXP2530 2ND LENS FRAME MOVE UNIT 1
205 VXQ1521 MAIN FRAME 1
206 VXQ1534 OIS UNIT 1
207 VXP2923 IRIS UNIT 1
208 L6HA64NC0003 ZOOM MOTOR UNIT 1
209 L6HA66NC0012 STEPPING MOTORS 1
210 VMS7638 GUIDE POLE 1
211 VMS7638 GUIDE POLE 1
212 VXP2531 4TH LENS FRAME MOVE UNIT 1
217 VDW1213 MASTER FLANGE 1
218 VDL1748 OPTICAL FILTER 1
219 VXW0938 LENS UNIT 1
220 VGQ9810 CCD HEAT TRANSFER SHEET 1
B201 XQN16+CJ7FJ SCREW 1
B202 XQN16+CJ7FJ SCREW 1
B203 XQN16+CJ7FJ SCREW 1
B204 XQN16+CJ5FJ SCREW 1
B205 XQN16+CJ5FJ SCREW 1
B206 XQN16+CJ5FJ SCREW 1
B207 XQN16+CJ5FJ SCREW 1
B208 XQN16+CJ5FJ SCREW 1
B209 XQN16+CJ5FJ SCREW 1
B210 XQN16+CJ5FJ SCREW 1
B211 XQN16+CJ5FJ SCREW 1
B212 XQN16+CJ5FJ SCREW 1
B213 XQN16+CJ5FJ SCREW 1
S-25
