– 74 –
R201 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R202 1-216-851-11 METAL CHIP 330K 5% 1/16W
R203 1-216-837-11 METAL CHIP 22K 5% 1/16W
R204 1-216-838-11 METAL CHIP 27K 5% 1/16W
R205 1-218-941-11 RES,CHIP 100 5% 1/16W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R207 1-216-841-11 METAL CHIP 47K 5% 1/16W
R208 1-218-949-11 RES,CHIP 470 5% 1/16W
R209 1-216-845-11 METAL CHIP 100K 5% 1/16W
R210 1-216-813-11 METAL CHIP 220 5% 1/16W
R211 1-216-837-11 METAL CHIP 22K 5% 1/16W
R212 1-216-845-11 METAL CHIP 100K 5% 1/16W
R213 1-216-849-11 METAL CHIP 220K 5% 1/16W
R214 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R215 1-216-845-11 METAL CHIP 100K 5% 1/16W
R216 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R217 1-218-990-11 SHORT 0
R218 1-218-983-11 RES,CHIP 330K 5% 1/16W
R219 1-218-977-11 RES,CHIP 100K 5% 1/16W
R220 1-216-833-11 METAL CHIP 10K 5% 1/16W
R221 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R222 1-216-797-11 METAL CHIP 10 5% 1/16W
R223 1-216-864-11 METAL CHIP 0 5% 1/16W
R224 1-216-864-11 METAL CHIP 0 5% 1/16W
R301 1-216-797-11 METAL CHIP 10 5% 1/16W
R302 1-216-840-11 METAL CHIP 39K 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-833-11 METAL CHIP 10K 5% 1/16W
R305 1-216-833-11 METAL CHIP 10K 5% 1/16W
R306 1-216-833-11 METAL CHIP 10K 5% 1/16W
R307 1-216-797-11 METAL CHIP 10 5% 1/16W
R308 1-216-833-11 METAL CHIP 10K 5% 1/16W
R309 1-216-833-11 METAL CHIP 10K 5% 1/16W
R310 1-216-851-11 METAL CHIP 330K 5% 1/16W
R311 1-216-821-11 METAL CHIP 1K 5% 1/16W
R312 1-216-851-11 METAL CHIP 330K 5% 1/16W
R313 1-216-821-11 METAL CHIP 1K 5% 1/16W
R314 1-216-805-11 METAL CHIP 47 5% 1/16W
R315 1-216-805-11 METAL CHIP 47 5% 1/16W
R316 1-218-937-11 RES,CHIP 47 5% 1/16W
R317 1-218-955-11 RES,CHIP 1.5K 5% 1/16W
R318 1-216-809-11 METAL CHIP 100 5% 1/16W
R319 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R320 1-216-833-11 METAL CHIP 10K 5% 1/16W
R321 1-216-833-11 METAL CHIP 10K 5% 1/16W
R322 1-216-864-11 METAL CHIP 0 5% 1/16W
R323 1-216-821-11 METAL CHIP 1K 5% 1/16W
R324 1-216-833-11 METAL CHIP 10K 5% 1/16W
R325 1-218-937-11 RES,CHIP 47 5% 1/16W
R326 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R327 1-216-809-11 METAL CHIP 100 5% 1/16W
R328 1-218-945-11 RES,CHIP 220 5% 1/16W
R329 1-216-833-11 METAL CHIP 10K 5% 1/16W
R330 1-218-965-11 RES,CHIP 10K 5% 1/16W
R401 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R402 1-216-835-11 METAL CHIP 15K 5% 1/16W
R403 1-216-797-11 METAL CHIP 10 5% 1/16W
R404 1-216-833-11 METAL CHIP 10K 5% 1/16W
R405 1-216-833-11 METAL CHIP 10K 5% 1/16W
R406 1-216-833-11 METAL CHIP 10K 5% 1/16W
R407 1-216-797-11 METAL CHIP 10 5% 1/16W
R408 1-218-929-11 RES,CHIP 10 5% 1/16W
R409 1-218-973-11 RES,CHIP 47K 5% 1/16W
R410 1-218-969-11 RES,CHIP 22K 5% 1/16W
R411 1-218-969-11 RES,CHIP 22K 5% 1/16W
R412 1-218-969-11 RES,CHIP 22K 5% 1/16W
R413 1-218-973-11 RES,CHIP 47K 5% 1/16W
R414 1-218-973-11 RES,CHIP 47K 5% 1/16W
R415 1-218-973-11 RES,CHIP 47K 5% 1/16W
R416 1-218-973-11 RES,CHIP 47K 5% 1/16W
R417 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R418 1-216-809-11 METAL CHIP 100 5% 1/16W
R419 1-218-948-11 RES,CHIP 100 5% 1/16W
R420 1-218-965-11 RES,CHIP 10K 5% 1/16W
R421 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R422 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R423 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R424 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R425 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R426 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R427 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R428 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R429 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R430 1-218-973-11 RES,CHIP 47K 5% 1/16W
R431 1-218-973-11 RES,CHIP 47K 5% 1/16W
R432 1-216-841-11 METAL CHIP 47K 5% 1/16W
R433 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R434 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R435 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R436 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R437 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R438 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R439 1-218-973-11 RES,CHIP 47K 5% 1/16W
R440 1-218-990-11 SHORT 0
R441 1-218-953-11 RES,CHIP 1K 5% 1/16W
R442 1-218-977-11 RES,CHIP 100K 5% 1/16W
R443 1-218-977-11 RES,CHIP 100K 5% 1/16W
R444 1-218-977-11 RES,CHIP 100K 5% 1/16W
R445 1-218-949-11 RES,CHIP 470 5% 1/16W
R446 1-218-977-11 RES,CHIP 100K 5% 1/16W
R447 1-218-975-11 RES,CHIP 68K 5% 1/16W
R448 1-218-977-11 RES,CHIP 100K 5% 1/16W
R449 1-216-821-11 METAL CHIP 1K 5% 1/16W
R450 1-216-821-11 METAL CHIP 1K 5% 1/16W
R451 1-216-809-11 METAL CHIP 100 5% 1/16W
R452 1-216-821-11 METAL CHIP 1K 5% 1/16W
R453 1-216-857-11 METAL CHIP 1M 5% 1/16W
R454 1-216-857-11 METAL CHIP 1M 5% 1/16W
R455 1-216-821-11 METAL CHIP 1K 5% 1/16W
R456 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R457 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R458 1-216-799-11 METAL CHIP 15 5% 1/16W
R459 1-216-855-11 METAL CHIP 680K 5% 1/16W
R460 1-216-855-11 METAL CHIP 680K 5% 1/16W
R461 1-216-853-11 METAL CHIP 470K 5% 1/16W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
