– 75 –
R462 1-216-851-11 METAL CHIP 330K 5% 1/16W
R463 1-216-851-11 METAL CHIP 330K 5% 1/16W
R464 1-216-850-11 METAL CHIP 270K 5% 1/16W
R465 1-216-845-11 METAL CHIP 100K 5% 1/16W
R466 1-216-841-11 METAL CHIP 47K 5% 1/16W
R467 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R468 1-216-843-11 METAL CHIP 68K 5% 1/16W
R469 1-216-839-11 METAL CHIP 33K 5% 1/16W
R470 1-216-845-11 METAL CHIP 100K 5% 1/16W
R471 1-216-849-11 METAL CHIP 220K 5% 1/16W
R472 1-216-849-11 METAL CHIP 220K 5% 1/16W
R473 1-216-843-11 METAL CHIP 68K 5% 1/16W
R474 1-216-847-11 METAL CHIP 150K 5% 1/16W
R475 1-216-864-11 METAL CHIP 0 5% 1/16W
R476 1-216-864-11 METAL CHIP 0 5% 1/16W
R477 1-216-844-11 METAL CHIP 82K 5% 1/16W
R478 1-216-845-11 METAL CHIP 100K 5% 1/16W
R479 1-216-850-11 METAL CHIP 270K 5% 1/16W
R480 1-216-851-11 METAL CHIP 330K 5% 1/16W
R481 1-216-853-11 METAL CHIP 470K 5% 1/16W
R482 1-216-855-11 METAL CHIP 680K 5% 1/16W
R483 1-216-797-11 METAL CHIP 10 5% 1/16W
R484 1-216-845-11 METAL CHIP 100K 5% 1/16W
R485 1-216-833-11 METAL CHIP 10K 5% 1/16W
R486 1-216-833-11 METAL CHIP 10K 5% 1/16W
R487 1-216-833-11 METAL CHIP 10K 5% 1/16W
R488 1-216-833-11 METAL CHIP 10K 5% 1/16W
R489 1-218-965-11 RES,CHIP 10K 5% 1/16W
R490 1-216-833-11 METAL CHIP 10K 5% 1/16W
R491 1-218-965-11 RES,CHIP 10K 5% 1/16W
R492 1-218-965-11 RES,CHIP 10K 5% 1/16W
R493 1-218-965-11 RES,CHIP 10K 5% 1/16W
R494 1-218-953-11 RES,CHIP 1K 5% 1/16W
R495 1-218-965-11 RES,CHIP 10K 5% 1/16W
R496 1-218-965-11 RES,CHIP 10K 5% 1/16W
R497 1-218-965-11 RES,CHIP 10K 5% 1/16W
R498 1-218-965-11 RES,CHIP 10K 5% 1/16W
R499 1-216-849-11 METAL CHIP 220K 5% 1/16W
< VARIABLE RESISTOR >
RV101 1-237-870-11 RES, VAR, CARBON 20K (ATT)
RV201 1-241-481-11 RES, ADJ, CERMET 100K
(SSB ZERO BEAT)
RV202 1-241-481-11 RES, ADJ, CERMET 100K(SD)
RV203 1-241-481-11 RES, ADJ, CERMET 100K
(AM 2ND LOCAL)
RV301 1-241-479-11 RES, ADJ, CERMET 22K
(FM STEREO)
RV302 1-241-849-11 RES, VAR, CARBON 50K (VOL ∑)
RV401 1-241-481-11 RES, ADJ, CERMET 100K(120mb)
RV402 1-241-481-11 RES, ADJ, CERMET 100K(31mb)
RV403 1-241-482-11 RES, ADJ, CERMET 220K(90mb)
RV404 1-241-481-11 RES, ADJ, CERMET 100K(25mb)
RV405 1-241-482-11 RES, ADJ, CERMET 220K(75mb)
RV406 1-241-481-11 RES, ADJ, CERMET 100K(22mb)
RV407 1-241-482-11 RES, ADJ, CERMET 220K(60mb)
RV408 1-241-482-11 RES, ADJ, CERMET 220K(19mb)
RV409 1-241-482-11 RES, ADJ, CERMET 220K(49mb)
RV410 1-241-482-11 RES, ADJ, CERMET 220K(16mb)
RV411 1-241-482-11 RES, ADJ, CERMET 220K(41mb)
RV412 1-241-482-11 RES, ADJ, CERMET 220K(13mb)
< SWITCH >
S101 1-771-246-21 SWITCH, SLIDE (ATT)
S301 1-572-922-11 SWITCH, SLIDE (TONE)
< TRANSFORMER >
T101 1-423-983-41 TRANSFORMER, HIGH FREQUENCY
T102 1-403-629-41 COIL (WITH CORE) (OSC)
T103 1-423-981-11 TRANSFORMER, HIGH FREQUENCY
T104 1-403-633-41 TRANSFORMER, IF (AM 1ST IF)
T105 1-403-604-41 TRANSFORMER, IF (AM 1ST IF)
T106 1-411-446-21 COIL (FM ANT) (FM TRACKING)
T107 1-411-445-21 COIL (FM RF) (FM TRACKING)
T201 1-403-638-41 COIL (WITH CORE) (OSC)
(FM FREQUENCY COVERAGE)
T401 1-433-539-21 TRANSFORMER, EL
T402 1-449-021-21 COIL, DC/DC CONVERTER
T403 1-450-531-21 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X201 1-760-200-11 VIBRATOR, CERAMIC (3.640MHz)
X202 1-760-197-11 VIBRATOR, CRYSTAL (55.390MHz)
X401 1-579-744-21 VIBRATOR, CRYSTAL (75kHz)
< FILTER >
XF101 1-760-198-11 FILTER, CRYSTAL
**************************************************************
* A-3663-171-A MICROCOMPUTER BOARD, COMPLETE
********************************
Caution :
When replacing the microcomputer board, remove IC503 from the older
circuit board and add it to the new circuit board. This allows continued use
of the user’s preset memory.
1-672-548-11 FLEXIBLE BOARD
1-694-491-11 CONDUCTIVE BOARD,CONNECTION(A)
1-694-492-11 CONDUCTIVE BOARD,CONNECTION(B)
3-031-516-01 HOLDER (LCD)
3-031-517-01 CASE (LCD)
< CAPACITOR >
C501 1-115-156-11 CERAMIC CHIP 1uF 10V
C502 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C503 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C504 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C505 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C506 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C507 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C508 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C509 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C511 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C512 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C514 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
