— 101 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
R831 1-216-049-11 RES-CHIP 1K 5% 1/10W
R832 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R832 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R833 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R833 1-216-689-11 RES-CHIP 39K 5% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R834 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R835 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R836 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R837 1-208-808-11 METAL CHIP 12K 0.50% 1/10W
R838 1-247-807-31 CARBON 100 5% 1/4W
R839 1-216-025-11 RES-CHIP 100 5% 1/10W
R840 1-216-093-91 RES-CHIP 68K 5% 1/10W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R841 1-208-802-11 METAL CHIP 6.8K 0.50% 1/10W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R841 1-208-806-11 METAL CHIP 10K 0.50% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R842 1-208-796-11 METAL CHIP 3.9K 0.50% 1/10W
R845 1-249-441-11 CARBON 100K 5% 1/4W
R846 1-249-441-11 CARBON 100K 5% 1/4W
R847 1-249-441-11 CARBON 100K 5% 1/4W
R848 1-215-876-00 METAL OXIDE 15K 5% 1W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R848 1-215-894-11 METAL OXIDE 2.2K 5% 2W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R849 1-215-920-11 METAL OXIDE 3.3K 5% 3W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R849 1-216-486-21 METAL OXIDE 8.2K 5% 3W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R850 1-216-486-21 METAL OXIDE 8.2K 5% 3W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R851 1-215-894-11 METAL OXIDE 2.2K 5% 2W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R851 1-215-922-11 METAL OXIDE 6.8K 5% 3W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R852 1-215-922-11 METAL OXIDE 6.8K 5% 3W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R854 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R854 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R855 1-216-089-91 RES-CHIP 47K 5% 1/10W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R855 1-216-091-00 RES-CHIP 56K 5% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R857 1-208-818-11 METAL CHIP 33K 0.50% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R890 1-216-097-11 RES-CHIP 100K 5% 1/10W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R860 1-208-806-11 METAL CHIP 10K 0.50% 1/10W
R862 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R863 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R864 1-216-033-00 RES-CHIP 220 5% 1/10W
R865 1-216-097-11 RES-CHIP 100K 5% 1/10W
R866 1-249-429-11 CARBON 10K 5% 1/4W
R867 1-216-073-91 RES-CHIP 10K 5% 1/10W
R868 1-216-073-91 RES-CHIP 10K 5% 1/10W
R869 1-216-097-11 RES-CHIP 100K 5% 1/10W
R870 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R871 1-215-489-00 METAL 680K 1% 1/4W
R872 1-216-121-11 RES-CHIP 1M 5% 1/10W
R873 1-216-073-91 RES-CHIP 10K 5% 1/10W
R874 1-216-037-00 RES-CHIP 330 5% 1/10W
R875 1-216-035-00 RES-CHIP 270 5% 1/10W
TRANSFORMER
T801 1-424-584-11 TRANSFORMER, DYNAMIC FOCUS
HX
* A-1372-817-A HX BOARD, MOUNTED
CONNECTOR
* CN4001 1-564-518-11 PLUG,CONNECTOR 3P
RESISTOR
R4001 1-216-025-11 RES-CHIP 100 5% 1/10W
R4002 1-216-045-00 RES-CHIP 680 5% 1/10W
R4003 1-216-047-91 RES-CHIP 820 5% 1/10W
R4004 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R4005 1-216-069-00 RES-CHIP 6.8K 5% 1/10W
SWITCH
S4001 1-762-196-21 SWITCH TACTILE
S4002 1-762-196-21 SWITCH TACTILE
S4003 1-762-196-21 SWITCH TACTILE
S4004 1-762-196-21 SWITCH TACTILE
S4005 1-762-196-21 SWITCH TACTILE
S4006 1-762-196-21 SWITCH TACTILE
D
HX
