— 102 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
HA
* A-1372-825-A HA BOARD, MOUNTED
(KV-27FV17/29FV17/29FV17C ONLY)
CAPACITOR
C4202 1-117-534-91 ELECT 1µF 20% 100V
C4203 1-117-534-91 ELECT 1µF 20% 100V
CONNECTOR
* CN4200 1-564-512-11 PLUG,CONNECTOR 9P
DIODE
D4216 8-719-069-60 DIODE UDZSTE-179.1B
D4217 8-719-108-12 DIODE RD9.1EW-T1
D4218 8-719-108-12 DIODE RD9.1EW-T1
D4219 8-719-108-12 DIODE RD9.1EW-T1
D4299 8-719-069-60 DIODE UDZSTE-179.1B
JACK
J4221 1-770-361-11 TERMINAL BLOCK, S
RESISTOR
R4206 1-249-425-11 CARBON 4.7K 5% 1/4W
R4207 1-216-113-00 RES-CHIP 470K 5% 1/10W
R4209 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R4210 1-249-419-11 CARBON 1.5K 5% 1/4W
R4211 1-249-421-11 CARBON 2.2K 5% 1/4W
R4212 1-249-427-11 CARBON 6.8K 5% 1/4W
R4228 1-216-113-00 RES-CHIP 470K 5% 1/10W
SWITCH
S4217 1-762-196-21 SWITCH TACTILE
S4218 1-762-196-21 SWITCH TACTILE
S4219 1-762-196-21 SWITCH TACTILE
S4220 1-762-196-21 SWITCH TACTILE
HB
* A-1372-826-A HB (VAR) BOARD, MOUNTED
(KV-27FV17/29FV17/29FV17C ONLY)
CAPACITOR
C4050 1-104-665-11 ELECT 100µF 20% 25V
CONNECTOR
* CN4050 1-564-520-11 PLUG,CONNECTOR 5P
DIODE
D4051 8-719-057-09 DIODE LNJ801LPDJA
IC
IC4050 8-742-211-20 HYB IC SBX3071-71
CHIP CONDUCTOR
JR4051 1-216-295-91 SHORT
RESISTOR
R4050 1-249-401-11 CARBON 47 5% 1/4W
R4051 1-216-049-11 RES-CHIP 1K 5% 1/10W
K
* A-1380-633-A K (VAR) BOARD, MOUNTED
(KV-27FV17/29FV17/29FV17C ONLY)
* A-1380-632-A K (VAR) BOARD, MOUNTED
(KV-27FS13/27FV17/32FS13/32FS17/34FS13C/
34FS17 ONLY)
CAPACITOR
C201 1-126-963-11 ELECT 4.7µF 20% 50V
C202 1-126-963-11 ELECT 4.7µF 20% 50V
C404 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C405 1-163-034-91 CERAMIC CHIP 0.033µF 50V
C406 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C407 1-164-222-91 CERAMIC CHIP 0.22µF 25V
C408 1-164-222-91 CERAMIC CHIP 0.22µF 25V
C409 1-163-011-11 CERAMIC CHIP 0.0015µF 10% 50V
C410 1-163-034-91 CERAMIC CHIP 0.033µF 50V
C411 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C412 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C413 1-126-963-11 ELECT 4.7µF 20% 50V
C414 1-126-963-11 ELECT 4.7µF 20% 50V
C415 1-126-963-11 ELECT 4.7µF 20% 50V
C416 1-126-963-11 ELECT 4.7µF 20% 50V
C417 1-126-963-11 ELECT 4.7µF 20% 50V
C418 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C419 1-164-346-11 CERAMIC CHIP 1µF 16V
C422 1-126-963-11 ELECT 4.7µF 20% 50V
C423 1-126-963-11 ELECT 4.7µF 20% 50V
C424 1-164-005-11 CERAMIC CHIP 0.47µF 25V
(KV-27FV17/29FV17/29FV17C ONLY)
C425 1-164-346-11 CERAMIC CHIP 1µF 16V
(KV-27FV17/29FV17/29FV17C ONLY)
C426 1-126-960-11 ELECT 1µF 20% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C427 1-126-968-11 ELECT 100µF 20% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C428 1-126-968-11 ELECT 100µF 20% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
HA
HB
K
