KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
C429 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C430 1-164-222-91 CERAMIC CHIP 0.22µF 25V
(KV-27FV17/29FV17/29FV17C ONLY)
C431 1-163-038-91 CERAMIC CHIP 0.1µF 25V
(KV-27FV17/29FV17/29FV17C ONLY)
C432 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C433 1-164-346-11 CERAMIC CHIP 1µF 16V
(KV-27FV17/29FV17/29FV17C ONLY)
C434 1-163-038-91 CERAMIC CHIP 0.1µF 25V
(KV-27FV17/29FV17/29FV17C ONLY)
C440 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C441 1-126-933-11 ELECT 100µF 20% 16V
C446 1-126-933-11 ELECT 100µF 20% 16V
C450 1-126-963-11 ELECT 4.7µF 20% 50V
C451 1-126-963-11 ELECT 4.7µF 20% 50V
C455 1-164-005-11 CERAMIC CHIP 0.47µF 25V
(KV-27FV17/29FV17/29FV17C ONLY)
C456 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C457 1-163-034-91 CERAMIC CHIP 0.033µF 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C458 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C460 1-126-963-11 ELECT 4.7µF 20% 50V
(KV-27FV17/29FV17/29FV17C ONLY)
C475 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C490 1-216-295-91 SHORT
CONNECTOR
* CN402 1-564-506-11 PLUG,CONNECTOR 3P
CN450 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
CN451 1-564-505-11 PLUG,CONNECTOR 2P
IC
IC403 8-759-658-19 IC NJM2198-TE2
(KV-27FV17/29FV17/29FV17C ONLY)
IC404 8-759-697-77 IC NJW1130AG-TE2
CHIP CONDUCTOR
JR402 1-216-295-91 SHORT
(KV-27FV17/29FV17/29FV17C ONLY)
JR403 1-216-295-91 SHORT
JR404 1-216-295-91 SHORT
JR407 1-216-295-91 SHORT
(KV-27FV13/27FS17/32FS13/32FS17/34FS13C/
34FS17 ONLY)
JR408 1-216-295-91 SHORT
(KV-27FV13/27FS17/32FS13/32FS17/34FS13C/
34FS17 ONLY)
JR419 1-216-295-91 SHORT
(KV-27FV13/27FS17/32FS13/32FS17/34FS13C/
34FS17 ONLY)
JR440 1-216-295-91 SHORT
(KV-27FV13/27FS17/32FS13/32FS17/34FS13C/
34FS17 ONLY)
JR460 1-216-295-91 SHORT
(KV-27FV13/27FS17/32FS13/32FS17/34FS13C/
34FS17 ONLY)
JR420 1-216-295-91 SHORT
JR421 1-216-295-91 SHORT
JR422 1-216-295-91 SHORT
JR425 1-216-295-91 SHORT
JR426 1-216-295-91 SHORT
JR427 1-216-295-91 SHORT
JR428 1-216-295-91 SHORT
JR429 1-216-295-91 SHORT
JR474 1-216-295-91 SHORT
JR491 1-216-295-91 SHORT
COIL
L410 1-412-062-11 INDUCTOR 47µH
TRANSISTOR
Q430 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q431 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q432 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q433 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R403 1-216-295-91 SHORT
R404 1-216-025-11 RES-CHIP 100 5% 1/10W
R405 1-216-025-11 RES-CHIP 100 5% 1/10W
R407 1-216-025-11 RES-CHIP 100 5% 1/10W
R409 1-216-025-11 RES-CHIP 100 5% 1/10W
R410 1-216-025-11 RES-CHIP 100 5% 1/10W
R431 1-216-073-91 RES-CHIP 10K 5% 1/10W
R432 1-216-073-91 RES-CHIP 10K 5% 1/10W
R433 1-216-295-91 SHORT
R434 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R435 1-216-033-00 RES-CHIP 220 5% 1/10W
R436 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R437 1-216-033-00 RES-CHIP 220 5% 1/10W
R438 1-216-033-00 RES-CHIP 220 5% 1/10W
R442 1-216-033-00 RES-CHIP 220 5% 1/10W
R443 1-216-105-91 RES-CHIP 220K 5% 1/10W
R444 1-216-105-91 RES-CHIP 220K 5% 1/10W
R445 1-216-105-91 RES-CHIP 220K 5% 1/10W
R446 1-216-105-91 RES-CHIP 220K 5% 1/10W
R452 1-216-073-91 RES-CHIP 10K 5% 1/10W
(KV-27FV17/29FV17/29FV17C ONLY)
R455 1-216-081-00 RES-CHIP 22K 5% 1/10W
K
