— 17 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
ADJUSTMENT ITEMS (1 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
1 HSIZ Horizontal Size Adjustment 0-63 0 18 11 22
2 HPOS Horizontal Position Adjustment 0-63 13 13 20 22
3 VBOW Vertical Line Bowing Adj. 0-15 9 9 7 9
4 VANG Vertical Line Bowing Slant Adj. 0-15 8 3 9 7
5 VTRP TRAPEZIUM 0-31 19 18 21 17
6 HTRP Horiz. Trapezoid 0-15 6 6 0 2
7 TROT Tilt Correction 0-63 31 31 31 31
8 PAMP Horizontal PIN distortion Adj. 0-63 19 27 20 27
9 UPIN Upper PIN Distortion Adj. 0-63 34 41 37 38
10 LPIN Lower PIN Distortion Adj. 0-63 32 39 33 35
11 VSIZ Vertical Size Adjustment 0-63 32 51 33 51
12 VPOS Vertical Position Adj. 0-63 30 42 36 39
13 VLIN Vertical Lineality Adj. 0-15 3 5 3 4
14 SCOR Vertical "S" Correction Adjustment 0-15 6 8 8 8
15 VZOM 16:9 CRT Z Mode on/off 0-1 0 0 0
16 EHT Vertical High-Voltage Compensation 0-15 5 5 5
17 ASP Aspect Ratio Control 0-63 47 47 47
18 SCRL 16:9 CRT Z Mode Trans. Scroll 0-63 31 31 31
19 HBLK Horizontal Blanking on/off 0-1 1 1 1
20 LBLK Left Blanking Adjustment 0-15 **** 13 13
21 RBLK Rigth Blanking Adjustment 0-15 ***** 7 8
22 HDW Horizontal Drive Pulse Width 0-1 1 1 1
23 EWDC "Parabola" EW, D.C. Adjustment 0-1 0 0 0
24 LVLN Lower Screen BTM Vertical Line Adj. 0-15 0 0 0
25 UVLN Uppe Screen BTM Vertical Line Adj. 0-15 0 0 0
26 INTL INTERLACE 0-3 0 0 0
27 G2SW 0-1 0 0 0
28 G2LV 0-7 0 0 0
29 HOSC Horizontal VCO Oscillation Freq. 0-15 12 7 7
30 VSS Vertical Sync Slice Level 0-3 0 0 0
31 HSS Horizontal Sync Slice Level 0-1 0 0 0
32 HMSK For Macro Vision 0-1 0 0 0
33 VTMS Select Signal VTIM Pin 0-3 0 0 0
34 CDMD Vertical Count Down Mode Switching 0-3 3 * 3 3
35 AFC AFC Loop Gain Switching 0-3 0 0 0
36 FIFR Field Frequency 0-3 3 3 3
37 VBLK VBLKW 0-3 0 0 0
38 REFP REFP 0-1 0 0 0
39 JPSW JUMPSW 0-1 MENU 0 0
40 RDRV R Output Drive control 0-63 *** 31 40
41 GDRV G Output Drive control 0-63 25 22 42
42 BDRV B Output Drive control 0-63 25 21 31
43 RCUT R Output Cutoff control 0-63 31 31 31
44 GCUT G Output Cutoff control 0-63 15 13 12
45 BCUT B Output Cutoff control 0-63 12 14 15
46 SCON SUB CONT 0-15 8 11 11
47 SHUE Sub HUE adjustment 0-15 16 17 16
48 SCOL Sub COLOR adjustment 0-15 18 17 18
49 SBRT Sub BRIGHTNESS adjustment 0-31 16 15 16
50 CHUE SUB COLOR (RF) 0-31 7 6 6
51 CCOL SUB COLOR (RF) 0-31 7 7 4
52 UOFS YUV U OFFSET 0-15 7 7 7
53 VOFS YUV V OFFSET 0-15 7 7 7
54 RON R Output on/off 0-1 1 1 1
* CDMD = 3 for US & CND, CDMD = 0 for Other
*** RDRV = 41 for 27FS/32FS families, 31 for 27FV family
****LBLK = 0 for 27FV/29FV/32FS/34FS family, 5 FOR 27FS family
***** RBLK = 3 for 27FV/29FV/32FS/34FS family, 2 for 27FS family
