— 18 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
ADJUSTMENT ITEMS (2 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
55 GON G Output on/off 0-1 1 1 1
56 BON B Output on/off 0-1 1 1 1
57 AXPL Axis PAL 0-1 0 0 0
58 AXNT Axis NTSC 0-1 1 1 1
59 CBPF Chroma BPF on/off 0-1 1 1 1
60 CTRP Y TRAP FILTER on/off 0-1 1 1 1
61 COFF Color On/off 0-1 0 0 0
62 KOFF Set Color Killer 0-1 0 0 0
63 SSHP Sub SHARPNESS 0-15 5 5 5
64 SHPF SHARPNESS Circuit Fo 0-3 Palette Mode Controls This Register 2 2
65 PREL Pre-Shoot/ Over-Shoot 0-1 1 0 0
66 Y-DC DC transmission Ratio Switching 0-3 Palette Mode Controls This Register 2 2
67 GAMM Gamma Correction 0-3 Palette Mode Controls This Register 2 2
68 ABLM ABL Mode Switch 0-1 1 1 1
69 VTH ABL CD VHT Switching 0-1 1 1 1
70 YDEL Y Delay Time Control 0-15 7 7 7
71 NCOL No Color ID 0-1 1 1 1
72 FSC FSC Out on/off 0-1 1 1 1
73 K-ID Killer ID Control on/off 0-1 0 0 0
74 GDOF 0-31 3 3 3
75 BDOF 0-31 16 16 16
76 GCOF 0-31 16 16 16
77 BCOF 0-31 7 7 7
78 SYSC Color System 0-7 4 4 4
79 VENH Vertical Enhancement 0-7 Palette Mode Controls This Register 5 3
80 PDSO PDS OFF 0-1 0 0 0
81 CK CK 0-1 0 0 0
82 VNL VNL 0-15 3 3 3
83 HPK HPK 0-1 0 0 0
84 HPKO HPK OFF 0-1 Palette Mode Controls This Register 0 0
85 CORE CORE 0-3 2 1 1
86 TRAP TRAP 0-1 1 1 1
87 CHTR CH TRAP 0-1 0 0 0
88 CBPF CBPF 0-1 1 1 1
89 ENHO ENH OFF 0-1 0 0 0
90 NMRD NMRD 0-3 0 0 0
91 YAPS YAPS 0-3 3 3 3
92 CLKS CLKS 0-3 0 0 0
93 NSTD NSTDS 0-3 0 0 0
94 MSS MSS 0-3 0 0 0
95 KILS KILS 0-3 1 1 1
96 ADIN ADIN 0-1 0 0 0
97 EXCS EXCSS 0-3 1 1 1
98 CPP CPP 0-3 2 2 2
99 HDP HDP 0-7 4 4 4
100 CDL CDL 0-7 4 4 4
101 DYCR DYCOR 0-15 2 2 2
102 DYGN DYGAIN 0-15 10 10 10
103 DCCR DCCOR 0-15 3 3 3
104 DCGN DCGAIN 0-15 6 6 6
105 YNRL YNRLIM 0-3 1 1 1
106 CNRL CNRLIM 0-3 1 1 1
107 WSC WSC 0-3 1 1 1
108 VTRH VTRH 0-3 1 1 1
