— 19 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
ADJUSTMENT ITEMS (3 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
109 VTRR VTRR 0-3 1 1 1
110 LDSR LDSR 0-3 2 2 2
111 VAPG VAPGAIN 0-7 3 3 3
112 VAPI VAPINV 0-31 6 6 6
113 TEST TEST 0-1 0 0 0
114 YPFT YPFT 0-3 3 3 3
115 YPFG YPFG 0-15 7 7 7
116 CC3N CC3N 0-1 0 0 0
117 SELD 0-1 1 1 1
118 D2GN D2GAIN 0-7 4 5 5
119 YHCR YHCOR 0-3 0 0 0
120 YPFC YPFCOR 0-1 0 0 0
121 SHT SHT 0-3 0 0 0
122 MVT MVT 0-1 0 0 0
123 OTT OTT 0-1 0 0 0
124 CL2D CL2D 0-1 1 1 1
125 CLKG CLKGGT 0-1 0 0 0
126 HPLL HPLLFS 0-1 1 1 1
127 BPLL BPLLFS 0-1 0 0 0
128 FSCF FSCFG 0-1 0 0 0
129 PLLS PLLS 0-1 1 1 1
130 KILR KILR 0-15 3 3 3
131 HSSL HSSL 0-15 12 12 12
132 VSSL VSSL 0-15 8 8 8
133 BGPS BGPS 0-15 4 4 4
134 BGPW BGPW 0-15 10 10 10
135 ADCK ADCLKS 0-3 3 3 3
136 NDSW NSDSW 0-1 1 1 1
137 PFRN FREE_RUN 0-1 0 0 0
138 PRVS RVS 0-1 0 0 0
139 PCON CONTRAST 0-127 97 45 45
140 PUCO U-DAC 0-127 5 16 16
141 PVCO V-DAC 0-127 5 24 24
142 PHUE 0-31 12 15 15
143 PKIL KILLER 1 0 0 0
144 PSEP EXT_SC_SEL 0-3 1 2 2
145 PHIM 0-1 0 0 0
146 PSUB 0-1 0 0 0
147 PBGS BG_START 0-63 14 14 14
148 PDL0 0-15 10 6 6
149 PDL1 0-15 13 13 13
150 PBRT Y_OFFSET 0-31 25 25 25
151 PVP1 0 0 0
152 PUP1 0 0 0
153 PVP2 0 0 0
154 PUP2 0 0 0
155 PVP3 0 0 0
156 PUP3 0 0 0
157 PACS SET_ACC 0-1 1 1 1
158 PSDL YUV_Color (More Significant) 0-3 2 0 0
159 PDCO YUV_Color (Less Significant) 0-3 2 0 0
