— 20 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/ 32FS17/ 34FS13C/ 34FS17
service id's id5 19
ntsc
M37280MK-00SP VERB.O
Function
ID
Number
Mode
Signal
Type
00010011
Chip
Version
Data
Notes:
No. 1-206 show the order that each adjustment mode may be selected while in Service Mode.
Data Range shows the range of possible settings for each Adjustment Mode.
Initial Data shows the standard settings for each Adjustment Mode.
ADJUSTMENT ITEMS (4 OF 4)
Reg # ITEM FUNCTION RANGE
FIX
DATA
NTSC
27 VIDEO
NTSC
32 RF
AVERAGE
DATA 27
AVERAGE
DATA 32
160 PCGA C_GAIN 0-1 1 1 1
161 PAAF 0-1 0 0 0
162 PSU2 0-1 0 0 0
163 PCVF 0-1 0 0 0
164 PBIT BITSEL 0-1 0 0 0
165 PAFC AFCBITSEL 0-1 0 0 0
166 PACC ACC_LEVEL 0-63 21 22 22
167 PBUR BURST_CLK 0-1 0 0 0
168 PEVE EVENUPRA 0-1 0 0 0
169 PINW INV_WFF 0-1 0 0 0
170 PINR INV_REF 0-1 0 0 0
171 PREF RFF_FIX 0-1 0 0 0
172 PARE AUTO_REF 0-1 1 1 1
173 PAVE AVERAGE 0-1 0 0 0
174 PFRA FREE_RUN_ADJ 0-15 0 0 0
175 PPAL SUB_PALM_JUDGE 0-255 0 0 0
176 PHPO 0-31 9 7 6
177 PVPO 0-31 22 22 22
178 PHTI HT 0-15 5 9 9
179 PHAJ ADJ 0-15 1 1 1
180 PBGY BGY 0-15 0 0 0
181 PCRO CROSS_SEL 0-1 0 0 0
182 PPAR PALRY 0-63 2 2 2
183 PHPF HPFOFF 0-1 0 0 0
184 PFSC FSC_OUTPUT 0-1 0 0 0
185 PVCH SET_VCHIP 0-1 0 0 0
186 PVON VCHIP_ONLY 0-1 1 1 1
187 PVLN LINE_NUM 0-31 17 17 17
188 PVSB STB_DLY 0-255 64 64 64
189 PVLV L_LEVEL 0-255 130 130 130
190 SBAL Sub Balance 0-7 5 5 5
191 SBAS Sub Bass 0-7 **** 0 0
192 STRE Sub Treble 0-7 ***** 3 3
193 BBEL BBE Low 0-15 ****** 0 0
194 BBEH BBE High 0-15 ******* 0 0
195 BBE BBE 0-1 ******** 0 0
196 AUX SRS, Simulated 0-3 0 0 0
197 DISP O.S.D Display position 0-127 20 32 34
198 HCLW Horizontal Count Lower limit 0-255 16 16 16 16
199 HCHG Horizontal Count High limit 0-255 64 64 64 64
200 ID0 0-255 25 See ID Map
201 ID1 0-255 3 See ID Map
202 ID2 0-255 91 See ID Map
203 ID3 0-255 2 See ID Map
204 ID4 0-255 233 See ID Map
205 ID5 0-255 17 See ID Map
206 ID6 0-255 0 See ID Map
****SBAS = 0 for 27FV/29FV/32FS/34FS family, 5 for 27FS family
***** STRE = 3 for 27FV/29FV/32FS/34FS family, 2 for 27FS family
****** BBEL = 5 for 27FV family; 6 for 29FV family and 0 for 27FS/29FS/32FS family
******* BBEH = 5 for 27FV family; 7 for 29FV family and 0 for 27FS/29FS/32FS family
******** BBE = 1 for 27FV/29FV families and 0 for 27FS/29FS/32FS family
