— 82 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMMON PARTS LISTING FS SERIES
MA
* A-1304-200-A MA (VAR) MOUNTED PC BOARD (KV-27FS13 ONLY)
* A-1304-198-A MA (VAR) MOUNTED PC BOARD (KV-27FS17 ONLY)
* A-1304-203-A MA (VAR) MOUNTED PC BOARD
(KV-32FS13/34FS13C ONLY)
* A-1304-196-A MA (VAR) MOUNTED PC BOARD
(KV-32FS17/34FS17 ONLY)
CAPACITOR
C003 1-126-959-11 ELECT 0.47µF 20% 50V
C005 VARIANT (SEE VARIANT PARTS LIST)
C006 1-126-964-11 ELECT 10µF 20% 50V
C009 1-163-259-91 CERAMIC 220pF 5% 50V
C010 1-163-035-00 CERAMIC 0.047µF 50V
C011 1-163-259-91 CERAMIC 220pF 5% 50V
C012 1-163-009-91 CERAMIC 0.001µF 10% 50V
C015 1-163-231-11 CERAMIC 15pF 5% 50V
C016 1-163-231-11 CERAMIC 15pF 5% 50V
C017 1-126-960-11 ELECT 1µF 20% 50V
C019 1-163-259-91 CERAMIC 220pF 5% 50V
C020 1-163-038-91 CERAMIC 0.1µF 25V
C021 1-163-259-91 CERAMIC 220pF 5% 50V
C022 1-163-135-00 CERAMIC 560pF 5% 50V
C027 1-163-009-91 CERAMIC 0.001µF 10% 50V
C028 1-163-259-91 CERAMIC 220pF 5% 50V
C032 1-164-004-11 CERAMIC 0.1µF 10% 25V
C033 1-163-259-91 CERAMIC 220pF 5% 50V
C034 1-163-037-11 CERAMIC 0.022µF 10% 50V
C037 1-164-161-11 CERAMIC 0.0022µF 10% 50V
C038 1-126-935-11 ELECT 470µF 20% 16V
C039 1-126-964-11 ELECT 10µF 20% 50V
C040 1-163-229-11 CERAMIC 12pF 5% 50V
C041 1-163-237-11 CERAMIC 27pF 5% 50V
C042 1-163-259-91 CERAMIC 220pF 5% 50V
C043 1-163-009-91 CERAMIC 0.001µF 10% 50V
C044 1-163-009-91 CERAMIC 0.001µF 10% 50V
C045 1-164-161-11 CERAMIC 0.0022µF 10% 50V
C046 1-104-664-11 ELECT 47µF 20% 25V
C047 1-163-259-91 CERAMIC 220pF 5% 50V
C048 1-163-259-91 CERAMIC 220pF 5% 50V
C051 1-126-943-11 ELECT 2200µF 20% 25V
C060 1-163-005-91 CERAMIC 470pF 10% 50V
C062 1-126-959-11 ELECT 0.47µF 20% 50V
C063 1-137-194-81 FILM 0.47µF 5% 50V
C064 1-163-017-00 CERAMIC 0.0047µF 10% 50V
C070 1-163-009-91 CERAMIC 0.001µF 10% 50V
C071 1-163-009-91 CERAMIC 0.001µF 10% 50V
C076 1-163-259-91 CERAMIC 220pF 5% 50V
C077 1-163-259-91 CERAMIC 220pF 5% 50V
C091 1-115-185-11 CERAMIC 0.033µF 10% 50V
C093 1-163-259-91 CERAMIC 220pF 5% 50V
C097 1-163-009-91 CERAMIC 0.001µF 10% 50V
C099 1-126-960-11 ELECT 1µF 20% 50V
C151 VARIANT (SEE VARIANT PARTS LIST)
C153 VARIANT (SEE VARIANT PARTS LIST)
C154 VARIANT (SEE VARIANT PARTS LIST)
C155 VARIANT (SEE VARIANT PARTS LIST)
C156 VARIANT (SEE VARIANT PARTS LIST)
C157 VARIANT (SEE VARIANT PARTS LIST)
C302 1-163-021-91 CERAMIC 0.01µF 10% 50V
C303 1-163-021-91 CERAMIC 0.01µF 10% 50V
C304 1-163-021-91 CERAMIC 0.01µF 10% 50V
C305 1-126-933-11 ELECT 100µF 20% 16V
C307 1-163-227-11 CERAMIC 10pF 0.50pF 50V
C308 1-163-021-91 CERAMIC 0.01µF 10% 50V
C309 1-126-933-11 ELECT 100µF 20% 16V
C311 1-163-123-00 CERAMIC 180pF 5% 50V
C313 1-163-021-91 CERAMIC 0.01µF 10% 50V
C314 1-163-231-11 CERAMIC 15pF 5% 50V
C315 1-104-664-11 ELECT 47µF 20% 25V
C316 1-163-243-11 CERAMIC 47pF 5% 50V
C317 1-163-021-91 CERAMIC 0.01µF 10% 50V
C318 1-163-021-91 CERAMIC 0.01µF 10% 50V
C319 1-126-767-11 ELECT 1000µF 20% 16V
C320 1-164-005-11 CERAMIC 0.47µF 25V
C321 1-164-005-11 CERAMIC 0.47µF 25V
C322 1-164-005-11 CERAMIC 0.47µF 25V
C323 1-164-004-11 CERAMIC 0.1µF 10% 25V
C324 1-163-231-11 CERAMIC 15pF 5% 50V
C325 1-164-005-11 CERAMIC 0.47µF 25V
C326 1-164-004-11 CERAMIC 0.1µF 10% 25V
C328 1-164-004-11 CERAMIC 0.1µF 10% 25V
C329 1-164-004-11 CERAMIC 0.1µF 10% 25V
C330 1-126-960-11 ELECT 1µF 20% 50V
C331 1-163-021-91 CERAMIC 0.01µF 10% 50V
C332 1-163-010-11 CERAMIC 0.0012µF 10% 50V
C334 1-163-003-11 CERAMIC 330pF 10% 50V
C335 1-126-963-11 ELECT 4.7µF 20% 50V
C336 1-104-664-11 ELECT 47µF 20% 25V
C338 1-164-004-11 CERAMIC 0.1µF 10% 25V
C339 1-126-960-11 ELECT 1µF 20% 50V
C340 1-126-933-11 ELECT 100µF 20% 16V
C341 1-163-233-91 CERAMIC 18pF 5% 50V
C345 VARIANT (SEE VARIANT PARTS LIST)
C346 VARIANT (SEE VARIANT PARTS LIST)
MA
