— 83 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and
!
mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
COMMON PARTS LISTING FS SERIES
C347 VARIANT (SEE VARIANT PARTS LIST)
C348 1-164-005-11 CERAMIC 0.47µF 25V
C350 1-126-959-11 ELECT 0.47µF 20% 50V
C351 1-163-021-91 CERAMIC 0.01µF 10% 50V
C352 1-163-021-91 CERAMIC 0.01µF 10% 50V
C353 1-163-021-91 CERAMIC 0.01µF 10% 50V
C354 1-126-933-11 ELECT 100µF 20% 16V
C355 1-163-021-91 CERAMIC 0.01µF 10% 50V
C356 1-164-004-11 CERAMIC 0.1µF 10% 25V
C357 1-104-664-11 ELECT 47µF 20% 25V
C358 1-104-664-11 ELECT 47µF 20% 25V
C359 1-163-038-91 CERAMIC 0.1µF 25V
C360 1-126-959-11 ELECT 0.47µF 20% 50V
C361 1-163-038-91 CERAMIC 0.1µF 25V
C362 1-104-664-11 ELECT 47µF 20% 25V
C363 1-163-038-91 CERAMIC 0.1µF 25V
C364 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C365 1-137-194-81 FILM 0.47µF 5% 50V
C366 1-163-021-91 CERAMIC 0.01µF 10% 50V
C367 1-163-005-91 CERAMIC 470pF 10% 50V
C368 1-163-021-91 CERAMIC 0.01µF 10% 50V
C369 1-163-021-91 CERAMIC 0.01µF 10% 50V
C370 1-126-933-11 ELECT 100µF 20% 16V
C371 1-163-243-11 CERAMIC 47pF 5% 50V
C377 1-126-963-11 ELECT 4.7µF 20% 50V
C380 VARIANT (SEE VARIANT PARTS LIST)
C381 VARIANT (SEE VARIANT PARTS LIST)
C382 VARIANT (SEE VARIANT PARTS LIST)
C389 VARIANT (SEE VARIANT PARTS LIST)
C390 1-163-231-11 CERAMIC 15pF 5% 50V
C391 1-126-933-11 ELECT 100µF 20% 16V
C395 1-163-021-91 CERAMIC 0.01µF 10% 50V
C396 1-164-004-11 CERAMIC 0.1µF 10% 25V
C397 1-163-021-91 CERAMIC 0.01µF 10% 50V
C398 1-126-964-11 ELECT 10µF 20% 50V
C451 VARIANT (SEE VARIANT PARTS LIST)
C452 VARIANT (SEE VARIANT PARTS LIST)
C453 VARIANT (SEE VARIANT PARTS LIST)
C454 VARIANT (SEE VARIANT PARTS LIST)
CONNECTOR
* CN001 1-564-511-11 PLUG,CONNECTOR 8P
* CN002 1-560-124-00 PLUG,CONNECTOR (2.5MM) 4P
* CN003 1-564-512-11 PLUG,CONNECTOR 9P
* CN004 1-564-512-11 PLUG,CONNECTOR 9P
* CN005 1-764-333-11 PLUG,CONNECTOR 10P
* CN006 1-764-333-11 PLUG,CONNECTOR 10P
* CN302 1-564-507-11 PLUG,CONNECTOR 4P
* CN304 VARIANT (SEE VARIANT PARTS LIST)
* CN305 VARIANT (SEE VARIANT PARTS LIST)
* CN309 1-564-506-11 PLUG,CONNECTOR 3P
* CN401 VARIANT (SEE VARIANT PARTS LIST)
DIODE
!
D001 8-719-069-54 DIODE UDZSTE-175.1B
D002 8-719-110-17 DIODE MTZJ-T-77-10B
D003 8-719-404-50 DIODE MA111-TX
D004 8-719-069-54 DIODE UDZSTE-175.1B
D005 8-719-109-89 DIODE MTZJ-T-77-5.6C
D006 8-719-069-60 DIODE UDZSTE-179.1B
D075 8-719-404-50 DIODE MA111-TX
D301 8-719-921-44 DIODE MTZJ-T-77-5.1C
D303 VARIANT (SEE VARIANT PARTS LIST)
D305 8-719-921-44 DIODE MTZJ-T-77-5.1C
D360 8-719-914-44 DIODE DAP202K-T-146
FERRITE BEAD
FB001 1-414-234-22 FERRITE 0µH
FB002 1-414-234-22 FERRITE 0µH
FB301 1-412-911-11 FERRITE 0µH
FILTER
FL301 1-239-847-11 FILTER, LOW PASS
FL302 1-239-847-11 FILTER, LOW PASS
FL303 1-239-847-11 FILTER, LOW PASS
IC
IC001 8-759-827-83 IC M37280MK-114SP
IC002 8-759-663-29 IC MM1476AF(TP)
IC003 8-759-699-33 IC M24C16-MN6T(A)
!
IC301 8-752-100-49 IC CXA2154AS
IC302 8-759-655-75 IC TC90A49P
JACK
JR001 1-216-295-91 SHORT
JR002 1-216-295-91 SHORT
JR003 1-216-295-91 SHORT
JR005 1-216-295-91 SHORT
JR006 1-216-295-91 SHORT
JR007 1-216-295-91 SHORT
JR008 1-216-295-91 SHORT
JR010 1-216-295-91 SHORT
JR011 1-216-295-91 SHORT
JR090 1-216-295-91 SHORT
JR100 1-216-295-91 SHORT
JR101 1-216-295-91 SHORT
JR296 1-216-295-91 SHORT
JR297 1-216-295-91 SHORT
JR298 1-216-295-91 SHORT
JR310 1-216-295-91 SHORT
JR311 1-216-295-91 SHORT
