— 84 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMMON PARTS LISTING FS SERIES
JR355 1-216-295-91 SHORT
JR378 1-216-295-91 SHORT
JR379 1-216-295-91 SHORT
JR391 1-216-295-91 SHORT
JR399 1-216-295-91 SHORT
JR402 1-216-295-91 SHORT
JR501 1-216-295-91 SHORT
JR502 1-216-295-91 SHORT
COIL
L002 1-412-064-11 INDUCTOR 100µH
L003 1-412-064-11 INDUCTOR 100µH
L040 1-408-963-11 INDUCTOR 2.7µH
L150 VARIANT (SEE VARIANT PARTS LIST)
L151 VARIANT (SEE VARIANT PARTS LIST)
L301 1-412-029-11 INDUCTOR 10µH
L302 1-412-031-11 INDUCTOR 47µH
L303 1-414-856-11 INDUCTOR 10µH
L304 1-414-856-11 INDUCTOR 10µH
L305 1-412-029-11 INDUCTOR 10µH
L308 1-412-064-11 INDUCTOR 100µH
L310 1-412-064-11 INDUCTOR 100µH
L350 1-414-856-11 INDUCTOR 10µH
L351 1-414-856-11 INDUCTOR 10µH
TRANSISTOR
Q001 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q002 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q003 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q004 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q006 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q082 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q151 VARIANT (SEE VARIANT PARTS LIST)
Q152 VARIANT (SEE VARIANT PARTS LIST)
Q302 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q303 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q305 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q310 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q349 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q350 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q351 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q352 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q354 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q355 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q356 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q358 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q359 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q365 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q368 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q369 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q370 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q375 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q378 VARIANT (SEE VARIANT PARTS LIST)
Q379 VARIANT (SEE VARIANT PARTS LIST)
Q380 VARIANT (SEE VARIANT PARTS LIST)
Q387 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q388 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q389 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
RESISTOR
R001 1-216-043-91 RES-CHIP 560 5% 1/10W
R002 1-216-041-00 RES-CHIP 470 5% 1/10W
R003 1-247-807-31 CARBON 100 5% 1/4W
R004 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R005 1-216-295-91 SHORT
R006 1-216-025-11 RES-CHIP 100 5% 1/10W
R007 1-216-025-11 RES-CHIP 100 5% 1/10W
R008 1-216-049-11 RES-CHIP 1K 5% 1/10W
R009 1-216-121-11 RES-CHIP 1M 5% 1/10W
R010 1-216-033-00 RES-CHIP 220 5% 1/10W
R011 1-216-033-00 RES-CHIP 220 5% 1/10W
R012 1-216-045-00 RES-CHIP 680 5% 1/10W
R013 1-249-417-11 CARBON 1K 5% 1/4W
R014 1-216-073-91 RES-CHIP 10K 5% 1/10W
R015 1-216-073-91 RES-CHIP 10K 5% 1/10W
R016 1-216-041-00 RES-CHIP 470 5% 1/10W
R017 1-208-798-11 METAL 4.7K 0.50% 1/10W
R018 1-249-409-11 CARBON 220 5% 1/4W
R019 1-216-113-00 RES-CHIP 470K 5% 1/10W
R020 1-216-033-00 RES-CHIP 220 5% 1/10W
R021 1-216-073-91 RES-CHIP 10K 5% 1/10W
R022 1-249-409-11 CARBON 220 5% 1/4W
R023 1-249-429-11 CARBON 10K 5% 1/4W
R024 1-249-409-11 CARBON 220 5% 1/4W
R025 1-249-426-11 CARBON 5.6K 5% 1/4W
R026 1-249-426-11 CARBON 5.6K 5% 1/4W
R027 1-249-426-11 CARBON 5.6K 5% 1/4W
R028 1-216-049-11 RES-CHIP 1K 5% 1/10W
R029 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R030 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R031 1-216-355-11 METAL 3.3 5% 1W
R032 1-216-033-00 RES-CHIP 220 5% 1/10W
R033 1-216-033-00 RES-CHIP 220 5% 1/10W
R034 1-216-033-00 RES-CHIP 220 5% 1/10W
R035 1-216-033-00 RES-CHIP 220 5% 1/10W
R036 1-216-049-11 RES-CHIP 1K 5% 1/10W
R037 1-249-409-11 CARBON 220 5% 1/4W
R038 1-216-049-11 RES-CHIP 1K 5% 1/10W
