— 96 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
IC
IC3500 8-759-568-27 IC UPD424210LE-60-E2
IC3501 8-759-594-44 IC UPD64082GF-3BA
IC3502 8-759-583-47 IC UPC2933T-E1
COIL
L3500 1-412-028-11 INDUCTOR 4.7µH
L3501 1-412-058-11 INDUCTOR 10µH
L3502 1-412-058-11 INDUCTOR 10µH
L3503 1-412-058-11 INDUCTOR 10µH
L3504 1-412-058-11 INDUCTOR 10µH
L3505 1-412-058-11 INDUCTOR 10µH
TRANSISTOR
Q3500 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3501 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3502 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3503 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3504 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3505 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3506 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3510 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3511 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3512 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3513 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3514 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3515 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3516 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3517 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
RESISTOR
R3503 1-216-017-91 RES-CHIP 47 5% 1/10W
R3504 1-216-295-91 SHORT
R3505 1-216-295-91 SHORT
R3506 1-216-295-91 SHORT
R3507 1-216-295-91 SHORT
R3508 1-216-295-91 SHORT
R3509 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3510 1-216-041-00 RES-CHIP 470 5% 1/10W
R3511 1-216-041-00 RES-CHIP 470 5% 1/10W
R3512 1-216-295-91 SHORT
R3514 1-216-025-11 RES-CHIP 100 5% 1/10W
R3515 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R3516 1-216-055-00 RES-CHIP 1.8K 5% 1/10W
R3517 1-216-025-11 RES-CHIP 100 5% 1/10W
R3518 1-216-025-11 RES-CHIP 100 5% 1/10W
R3519 1-216-295-91 SHORT
R3520 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R3521 1-216-041-00 RES-CHIP 470 5% 1/10W
R3522 1-216-041-00 RES-CHIP 470 5% 1/10W
R3523 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3524 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3525 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3526 1-216-105-91 RES-CHIP 220K 5% 1/10W
R3527 1-216-033-00 RES-CHIP 220 5% 1/10W
R3528 1-208-776-11 METAL CHIP 560 0.50% 1/10W
R3529 1-208-772-11 METAL CHIP 390 0.50% 1/10W
R3530 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3531 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3532 1-216-025-11 RES-CHIP 100 5% 1/10W
R3534 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3535 1-216-025-11 RES-CHIP 100 5% 1/10W
R3544 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3545 1-216-043-91 RES-CHIP 560 5% 1/10W
R3547 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3548 1-216-295-91 SHORT
R3549 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3550 1-208-780-11 METAL CHIP 820 0.50% 1/10W
R3551 1-208-776-11 METAL CHIP 560 0.50% 1/10W
R3552 1-208-764-11 METAL CHIP 180 0.50% 1/10W
R3553 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3554 1-216-047-91 RES-CHIP 820 5% 1/10W
R3555 1-216-075-00 RES-CHIP 12K 5% 1/10W
R3556 1-216-085-91 RES-CHIP 33K 5% 1/10W
R3557 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3558 1-216-017-91 RES-CHIP 47 5% 1/10W
R3559 1-216-295-91 SHORT
R3560 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3561 1-216-043-91 RES-CHIP 560 5% 1/10W
R3563 1-216-295-91 SHORT
R3564 1-216-295-91 SHORT
R3565 1-216-067-00 RES-CHIP 5.6K 5% 1/10W
R3566 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3567 1-216-043-91 RES-CHIP 560 5% 1/10W
R3568 1-216-047-91 RES-CHIP 820 5% 1/10W
R3569 1-216-057-00 RES-CHIP 2.2K 5% 1/10W
R3570 1-216-085-91 RES-CHIP 33K 5% 1/10W
R3571 1-216-075-00 RES-CHIP 12K 5% 1/10W
R3572 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3573 1-216-017-91 RES-CHIP 47 5% 1/10W
R3588 1-216-043-91 RES-CHIP 560 5% 1/10W
CRYSTAL
X3500 1-767-606-11 VIBRATOR, CRYSTAL
BC
