Sony KV-27FS13 - Page 97

— 97 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
P
* A-1190-391-A P BOARD, MOUNTED
(KV-27FS17/27FV17/29FV17/29FV17C/32FS17/
34FS17 ONLY)
CAPACITOR
C3300 1-164-346-11 CERAMIC CHIP 1µF 16V
C3301 1-164-346-11 CERAMIC CHIP 1µF 16V
C3302 1-164-346-11 CERAMIC CHIP 1µF 16V
C3303 1-104-660-91 ELECT 47µF 20% 16V
C3304 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C3305 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3308 1-104-660-91 ELECT 47µF 20% 16V
C3312 1-163-005-91 CERAMIC CHIP 470pF 10% 50V
C3313 1-163-009-91 CERAMIC CHIP 0.001µF 10% 50V
C3316 1-104-660-91 ELECT 47µF 20% 16V
C3317 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3318 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3319 1-104-660-91 ELECT 47µF 20% 16V
C3320 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3321 1-163-005-91 CERAMIC CHIP 470pF 10% 50V
C3322 1-163-034-91 CERAMIC CHIP 0.033µF 50V
C3323 1-164-222-91 CERAMIC CHIP 0.22µF 25V
C3324 1-163-233-91 CERAMIC CHIP 18pF 5% 50V
C3327 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C3328 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3329 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C3330 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3331 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3332 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3334 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3335 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3336 1-163-031-91 CERAMIC CHIP 0.01µF 50V
C3337 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3338 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C3339 1-126-965-91 ELECT 22µF 20% 50V
C3340 1-104-660-91 ELECT 47µF 20% 16V
C3341 1-163-031-91 CERAMIC CHIP 0.01µF 50V
CONNECTOR
CN3300 1-573-301-21 CONNECTOR, BOARD TO BOARD 20P
DIODE
D3301 8-719-404-50 DIODE MA111-TX
D3304 8-719-056-77 DIODE UDZ-TE-17-3.9B
IC
IC3301 6-700-200-01 IC M65665FP-D60S
COIL
L3300 1-412-058-11 INDUCTOR 10µH
L3301 1-410-682-31 INDUCTOR 470µH
L3302 1-412-058-11 INDUCTOR 10µH
L3303 1-412-058-11 INDUCTOR 10µH
TRANSISTOR
Q3300 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3301 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3302 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3304 8-729-926-14 TRANSISTOR 2SD1292
Q3305 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3307 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3308 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3309 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q3310 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q3312 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
RESISTOR
R3300 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3301 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3302 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3303 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3304 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3305 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3306 1-216-081-00 RES-CHIP 22K 5% 1/10W
R3307 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3308 1-216-081-00 RES-CHIP 22K 5% 1/10W
R3309 1-216-041-00 RES-CHIP 470 5% 1/10W
R3310 1-216-089-91 RES-CHIP 47K 5% 1/10W
R3311 1-216-045-00 RES-CHIP 680 5% 1/10W
R3312 1-216-295-91 SHORT
R3313 1-216-295-91 SHORT
R3314 1-216-295-91 SHORT
R3318 1-216-073-91 RES-CHIP 10K 5% 1/10W
R3319 1-216-073-91 RES-CHIP 10K 5% 1/10W
R3320 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R3321 1-216-295-91 SHORT
R3323 1-216-043-91 RES-CHIP 560 5% 1/10W
R3324 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3327 1-216-295-91 SHORT
R3328 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3329 1-216-295-91 SHORT
R3330 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3331 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3335 1-215-857-71 METAL OXIDE 10 5% 1W
P
