— 98 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
NOTE: The components identifi ed by shading
and ! mark are critical for safety. Replace only
with part number specifi ed.
NOTE: Les composants identifi es par un trame et une
marque ! sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specifi e.
REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
R3336 1-216-041-00 RES-CHIP 470 5% 1/10W
R3343 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3346 1-216-049-11 RES-CHIP 1K 5% 1/10W
R3347 1-216-073-91 RES-CHIP 10K 5% 1/10W
R3348 1-216-073-91 RES-CHIP 10K 5% 1/10W
R3350 1-216-295-91 SHORT
R3351 1-216-033-00 RES-CHIP 220 5% 1/10W
R3354 1-216-133-91 RES-CHIP 3.3M 5% 1/10W
R3359 1-216-295-91 SHORT
R3360 1-216-295-91 SHORT
R3361 1-216-295-91 SHORT
R3362 1-216-061-91 RES-CHIP 3.3K 5% 1/10W
R3363 1-216-085-91 RES-CHIP 33K 5% 1/10W
R3364 1-216-025-11 RES-CHIP 100 5% 1/10W
R3365 1-216-025-11 RES-CHIP 100 5% 1/10W
R3368 1-216-073-91 RES-CHIP 10K 5% 1/10W
R3369 1-216-037-00 RES-CHIP 330 5% 1/10W
R3372 1-216-295-91 SHORT
R3374 1-216-295-91 SHORT
CRYSTAL
X3301 1-781-377-11 VIBRATOR, CRYSTAL
CA
* A-1332-063-A CA (VAR) BOARD, MOUNTED
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
* A-1332-061-A CA (VAR) BOARD, MOUNTED
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
* 4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C701 1-104-664-11 ELECT 47µF 20% 25V
C702 1-136-165-00 FILM 0.1µF 5% 50V
C703 1-104-664-11 ELECT 47µF 20% 25V
C704 1-107-651-11 ELECT 4.7µF 20% 250V
C705 1-107-652-11 ELECT 10µF 20% 250V
C706 1-137-528-11 MYLAR 0.1µF 10% 250V
C707 1-162-114-00 CERAMIC 0.0047µF 2KV
C708 1-136-165-00 FILM 0.1µF 5% 50V
C709 1-126-934-11 ELECT 220µF 20% 16V
C710 1-126-964-11 ELECT 10µF 20% 50V
CONNECTOR
* CN701 1-564-506-11 PLUG,CONNECTOR 3P
CN702 1-695-915-11 TAB (CONTACT)
CN704 1-785-879-11 CONNECTOR, ONE TOUCH
* CN706 1-564-509-11 PLUG,CONNECTOR 6P
DIODE
D701 8-719-901-83 DIODE 1SS83TD
D702 8-719-901-83 DIODE 1SS83TD
D703 8-719-901-83 DIODE 1SS83TD
D704 8-719-302-43 DIODE RGP10GPKG23
IC
IC701 8-759-803-42 IC LA6500-FA
IC702 8-759-562-43 IC TDA6108JF/N1B
JACK
! J701 1-451-470-21 SOCKET, CRT
COIL
L701 1-408-613-31 INDUCTOR 68µH
TRANSISTOR
Q700 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q701 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R700 1-249-433-11 CARBON 22K 5% 1/4W
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-409-11 CARBON 220 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-249-421-11 CARBON 2.2K 5% 1/4W
R705 1-249-429-11 CARBON 10K 5% 1/4W
R706 1-249-381-11 CARBON 1 5% 1/4W
R707 1-249-383-11 CARBON 1.5 5% 1/4W
R708 1-247-807-31 CARBON 100 5% 1/4W
R709 1-247-807-31 CARBON 100 5% 1/4W
R710 1-247-807-31 CARBON 100 5% 1/4W
R711 1-260-328-11 CARBON 1K 5% 1/2W
R712 1-260-328-11 CARBON 1K 5% 1/2W
R713 1-260-328-11 CARBON 1K 5% 1/2W
R714 1-260-087-11 CARBON 100 5% 1/2W
R715 1-260-132-11 CARBON 560K 5% 1/2W
R716 1-260-123-11 CARBON 100K 5% 1/2W
R717 1-216-373-11 METAL OXIDE 2.2 5% 2W
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
R718 1-216-373-11 METAL OXIDE 2.2 5% 2W
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
R719 1-215-888-00 METAL OXIDE 220 5% 2W
R720 1-249-421-11 CARBON 2.2K 5% 1/4W
R721 1-249-421-11 CARBON 2.2K 5% 1/4W
VARIABLE RESISTOR
RV701 1-241-656-11 RES, ADJ, METAL FILM 110M
P
CA
