— 99 —
KV-27FS13/ 27FS17/ 27FV17/ 29FV17/ 29FV17C/ 32FS13/32FS17/ 34FS13C/ 34FS17
REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
COMPLETE PARTS LISTING
VA
* A-1342-550-A VA (VAR) BOARD, MOUNTED
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
* A-1342-549-A VA (VAR) BOARD, MOUNTED
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C805 1-129-763-61 FILM 0.033µF 5% 200V
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
C805 1-130-338-91 FILM 0.01µF 5% 630V
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
C811 1-129-765-00 FILM 0.047µF 5% 200V
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
C811 1-129-768-61 FILM 0.082µF 5% 200V
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
C901 1-107-667-11 ELECT 2.2µF 20% 160V
C902 1-130-491-00 MYLAR 0.047µF 5% 50V
C903 1-126-935-11 ELECT 470µF 20% 10V
C904 1-130-471-00 MYLAR 0.001µF 5% 50V
C905 1-106-383-00 MYLAR 0.047µF 10% 200V
C906 1-130-471-00 MYLAR 0.001µF 5% 50V
C907 1-107-638-11 ELECT 33µF 20% 160V
C908 1-126-935-11 ELECT 470µF 20% 10V
C909 1-161-830-00 CERAMIC 0.0047µF 500V
C910 1-104-999-11 MYLAR 0.1µF 10% 200V
C911 1-104-665-11 ELECT 100µF 20% 10V
C912 1-126-941-11 ELECT 470µF 20% 25V
C913 1-102-074-00 CERAMIC 0.001µF 10% 50V
C914 1-130-491-00 MYLAR 0.047µF 5% 50V
CONNECTOR
* CN901 1-564-508-11 PLUG,CONNECTOR 5P
* CN902 1-770-723-11 CONNECTOR, BOARD TO BOARD 8P
* CN904 1-564-507-11 PLUG,CONNECTOR 4P
DIODE
D804 8-719-302-43 DIODE RGP10GPKG23
D805 8-719-991-33 DIODE 1SS133T-77
D806 8-719-991-33 DIODE 1SS133T-77
D807 8-719-210-21 DIODE ERA82-004TP5
D901 8-719-110-88 DIODE MTZJ-T-77-39
D902 8-719-110-88 DIODE MTZJ-T-77-39
D903 8-719-991-33 DIODE 1SS133T-77
COIL
L801 1-406-989-21 INDUCTOR 10mH
L802 1-459-111-00 INDUCTOR 10mH
L901 1-412-528-11 INDUCTOR 18µH
TRANSISTOR
Q807 8-729-931-45 TRANSISTOR IRF614
Q808 8-729-140-97 TRANSISTOR 2SB734-T-34
Q901 8-729-017-06 TRANSISTOR 2SC4793
Q902 8-729-017-05 TRANSISTOR 2SA1837
Q903 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q904 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
Q905 8-729-119-76 TRANSISTOR 2SA1309A-QRSTA
Q906 8-729-423-33 TRANSISTOR 2SC3311A-QRSTA
RESISTOR
R818 1-216-025-11 RES-CHIP 100 5% 1/10W
R826 1-249-421-11 CARBON 2.2K 5% 1/4W
R876 1-216-049-11 RES-CHIP 1K 5% 1/10W
R901 1-249-401-11 CARBON 47 5% 1/4W
R902 1-249-386-11 CARBON 2.7 5% 1/4W
R903 1-249-414-11 CARBON 560 5% 1/4W
R904 1-249-432-11 CARBON 18K 5% 1/4W
R905 1-249-417-11 CARBON 1K 5% 1/4W
R906 1-249-432-11 CARBON 18K 5% 1/4W
R907 1-249-386-11 CARBON 2.7 5% 1/4W
R908 1-249-414-11 CARBON 560 5% 1/4W
R909 1-260-312-11 CARBON 47 5% 1/2W
R910 1-216-476-11 METAL OXIDE 180 5% 3W
R911 1-249-403-11 CARBON 68 5% 1/4W
R912 1-249-409-11 CARBON 220 5% 1/4W
R913 1-249-403-11 CARBON 68 5% 1/4W
R914 1-249-410-11 CARBON 270 5% 1/4W
R915 1-249-417-11 CARBON 1K 5% 1/4W
R916 1-249-417-11 CARBON 1K 5% 1/4W
R917 1-249-417-11 CARBON 1K 5% 1/4W
R918 1-247-807-31 CARBON 100 5% 1/4W
R919 1-247-807-31 CARBON 100 5% 1/4W
R920 1-249-416-11 CARBON 820 5% 1/4W
R921 1-249-429-11 CARBON 10K 5% 1/4W
R922 1-249-397-11 CARBON 22 5% 1/4W
R923 1-249-401-11 CARBON 47 5% 1/4W
D
* A-1343-875-A D (VAR) BOARD, MOUNTED
(KV-27FS13/27FS17/27FV17/29FV17/29FV17C ONLY)
* A-1343-874-A D (VAR) BOARD, MOUNTED
(KV-32FS13/32FS17/34FS13C/34FS17 ONLY)
CAPACITOR
C801 1-126-960-11 ELECT 1µF 20% 50V
C802 1-126-964-11 ELECT 10µF 20% 50V
C803 1-136-191-11 MYLAR 0.22µF 5% 63V
VA
D
