Specifications
46
Appendixes
Power requirements
DC 24 ±2.4 V
Input current
1.5 A, 3 A (inrush)
Operating temperature
0 ºC to 40 ºC (32 ºF to +104 ºF)
Storage temperature
–20ºC to +60ºC (–4ºF to +140ºF)
Operating humidity
20% to 80% (no condensation allowed)
Storage humidity
20% to 90% (no condensation allowed)
Operating pressure
700 hPa to 1,060 hPa
Storage pressure
700 hPa to 1,060 hPa
Mass Camera head: 90 g (3.2 oz)
Camera control unit: 4.5 kg (9 lb 15 oz)
Dimensions (w/h/d)
Camera head: 35 × 45 × 50 mm (1
7
/
16
×
1
13
/
16
× 2 inches)
Camera control unit: 200 × 88 × 341 mm
(7
7
/
8
× 3
1
/
2
× 13
1
/
2
inches)
Supplied accessories
See “Package Configuration” (page 11).
Pickup device
1
/
2
-inch type, CMOS image sensor
Effective picture elements:
1920 (H) × 1080 (V)
Format
3-chip RGB
Optical system
F2.2 or more (prism system)
Lens mount
C-mount
Sensitivity
F10 (Typical) (With 1080/60i, 89.9%
reflection, 2000 lx)
Minimum illumination
9 lx (F2.2, +21 dB)
Picture S/N
54 dB (Y) (Typical)
Horizontal resolution
1000TV lines or more
Modulation
45% (27.5 MHz)
Black level
3±1% (when “Black” in the Picture
Profile menu is set to ±0)
Registration
0.02%
Gain 0 to 21 dB, AGC
Shutter speed
1
/
60
to
1
/
16000
sec (when “Country” is
set to “PAL”) or
1
/
20000
sec (when
“Country” is set to “NTSC”).
Camera cable connector
20-pin, round
Input connectors
DC IN
DIN 3-pin, DC 24 V
EXT SYNC IN
BNC
Output connectors
VIDEO OUT
BNC, 1.0 Vp-p, 75 Ω, unbalanced
Specifications
General
Camera head
Inputs/outputs (camera control
unit)
