17
3-6.
BU HOLDER ASSEMBL
Y
3-7.
MO
T
OR (LO
ADING) ASSEMBL
Y (M10)
2
Two scews
(BV2.6)
2
Two scews
(BV2.6)
3
Two collars
(damper)
3
Two collars
(damper)
4
Two compression
springs
4
Two compression
springs
5
BU holder assembly
1
Turn the pully gear to align
the slider with of the rib.
(Refer to Fig. A.)
Fig. A
Slider
Rib
2
Two screws
(BV2.6)
4
Belt (loading
)
3
Gear assembly
6
Motor (loading) assembly (M10)
5
Two screws
(B2
×
3)
1
Connector
(CN14)
16
18
