Sony MDS-JA555ES Service Manual

MDS-JA555ES
5656
45.15 MHz
44.1 kHz
2.822 MHz
11.29 MHz
176.4 kHz
45.15 MHz
Approx.
0.16 Vp-p
Approx.
0.16 Vp-p
2.9 Vp-p
3.3 Vp-p
4.0 Vp-p
4.3 Vp-p
3.3 Vp-p
2.6 Vp-p
1.2 ± 0.2
Vp-p
1 TP166 (RF) (Play mode) 6 TP124 (BCK)
7 TP205 (FS256)
8 TP217 (FS4)
9 TP138 (1024FS)
2 TP108 (A) (Play mode)
3 TP102,T105 (E, F)
(Play mode)
4 TP219 (OSCI)
5 TP131 (LRCK)
32 kHz
7 MHz
44.1 kHz
2.822 MHz
5.644 MHz
11.289 MHz
3.4 Vp-p
3.3 Vp-p
5 Vp-p
5 Vp-p
5.8 Vp-p
5 Vp-p
1 IC800 qd (XOUT)
2 IC800 qa (XOUT-T)
3 IC301 th (LRCK)
4 IC301 tf (BCK)
5 IC301 wh (FCLK)
6 IC301 wj (MCLK)
45.158 MHz
11.289 MHz
44.1 kHz
2.822 MHz
5.644 MHz
22.579 MHz
5 Vp-p
4Vp-p
3.4 Vp-p
3.4 Vp-p
5 Vp-p
5 Vp-p
1 IC501 t; (LRCKI)
2 IC501 rl (BCKI)
3 IC502 tf (NSBCKO)
4 IC502 ta (512FSO)
5 IC502 rf (256FSO)
6 IC514 7 (O1)
2.59 MHz
3.3 Vp-p
1 IC771 yh (OSCO)
• Waveforms
BD SECTION AD SECTION DA SECTION FL SECTION
