Sony MDS-JA555ES Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
78
C851 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C852 1-131-347-00 TANTALUM 1uF 10% 35V
C853 1-126-934-11 ELECT 220uF 20% 10V
C854 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C855 1-126-022-11 ELECT 47uF 20% 25V
C856 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C858 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C859 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C860 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C861 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN302 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN303 1-691-770-11 PLUG (MICRO CONNECTOR) 8P
CN304 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
CN800 1-770-653-11 CONNECTOR, FFC/FPC 25P
CN801 1-568-440-11 SOCKET, CONNECTOR 17P
CN803 1-770-651-11 CONNECTOR, FFC/FPC 23P
CN804 1-779-289-11 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN806 1-569-490-11 SOCKET, CONNECTOR 3P
* CN807 1-770-639-11 CONNECTOR, FFC/FPC 8P
* CN808 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
* CN809 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D301 8-719-911-19 DIODE 1SS133T-72
D302 8-719-911-19 DIODE 1SS133T-72
D303 8-719-911-19 DIODE 1SS133T-72
D304 8-719-911-19 DIODE 1SS133T-72
D305 8-719-911-19 DIODE 1SS133T-72
D306 8-719-911-19 DIODE 1SS133T-72
D307 8-719-911-19 DIODE 1SS133T-72
D308 8-719-911-19 DIODE 1SS133T-72
D309 8-719-210-39 DIODE EC10QS-04-TE12L
D310 8-719-210-39 DIODE EC10QS-04-TE12L
D802 8-719-911-19 DIODE 1SS133T-72
D803 8-719-911-19 DIODE 1SS133T-72
D805 8-719-210-21 DIODE 11EQS04-TA2B
D806 8-719-200-82 DIODE 11ES2-TA2B
< IC >
IC301 8-759-280-17 IC CXD8512Q
IC302 8-759-330-53 IC CXD8493M-E1
IC303 8-759-701-65 IC M5F79M05L
IC304 8-759-604-35 IC M5F78M05L
IC305 8-759-712-02 IC NJM2114D
IC306 8-759-712-02 IC NJM2114D
IC307 8-759-712-02 IC NJM2114D
IC308 8-759-712-02 IC NJM2114D
IC800 8-759-596-80 IC M30624MG-215FP
IC801 8-759-242-70 IC TC7WU04F-TE12L
IC802 8-759-572-68 IC L88MS33T-MA
IC803 8-759-491-36 IC TC74VHCT244AF(EL)
IC804 8-759-174-16 IC TC74VHC244F(EL)
IC805 8-759-242-70 IC TC7WU04F-TE12L
< JUMPER RESISTOR >
JR803 1-216-295-91 SHORT 0
JR804 1-216-295-91 SHORT 0
< COIL >
L301 1-408-599-31 INDUCTOR 4.7uH
L302 1-408-599-31 INDUCTOR 4.7uH
L850 1-408-599-31 INDUCTOR 4.7uH
L851 1-408-599-31 INDUCTOR 4.7uH
L852 1-414-235-22 INDUCTOR CHIP 0UH
< TRANSISTOR >
Q880 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q881 8-729-027-43 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R301 1-259-404-11 CARBON 100 5% 1/6W
R304 1-259-380-11 CARBON 10 5% 1/6W
R308 1-259-404-11 CARBON 100 5% 1/6W
R309 1-216-025-91 RES,CHIP 100 5% 1/10W
R310 1-259-404-11 CARBON 100 5% 1/6W
R311 1-249-504-11 CARBON 10 5% 1/4W
R312 1-249-504-11 CARBON 10 5% 1/4W
R313 1-249-504-11 CARBON 10 5% 1/4W
R314 1-249-504-11 CARBON 10 5% 1/4W
R315 1-249-576-11 CARBON 10K 5% 1/4W
R316 1-249-576-11 CARBON 10K 5% 1/4W
R317 1-249-576-11 CARBON 10K 5% 1/4W
R318 1-249-576-11 CARBON 10K 5% 1/4W
R319 1-249-576-11 CARBON 10K 5% 1/4W
R320 1-249-576-11 CARBON 10K 5% 1/4W
R321 1-249-588-91 CARBON 33K 5% 1/4W
R322 1-249-588-91 CARBON 33K 5% 1/4W
R323 1-249-941-11 CARBON 5.6K 5% 1/4W
R324 1-249-941-11 CARBON 5.6K 5% 1/4W
R325 1-249-469-11 CARBON 100K 5% 1/4W
R326 1-249-469-11 CARBON 100K 5% 1/4W
R327 1-249-923-11 CARBON 1K 5% 1/4W
R328 1-249-923-11 CARBON 1K 5% 1/4W
R329 1-249-995-11 CARBON 1M 5% 1/4W
R330 1-249-995-11 CARBON 1M 5% 1/4W
R331 1-249-995-11 CARBON 1M 5% 1/4W
R332 1-249-995-11 CARBON 1M 5% 1/4W
R800 1-216-073-00 METAL CHIP 10K 5% 1/10W
R801 1-216-073-00 METAL CHIP 10K 5% 1/10W
R802 1-216-073-00 METAL CHIP 10K 5% 1/10W
R803 1-216-073-00 METAL CHIP 10K 5% 1/10W
(AEP,UK)
R804 1-216-073-00 METAL CHIP 10K 5% 1/10W
(US,CND)
R806 1-216-097-91 RES,CHIP 100K 5% 1/10W
(US,CND)
R807 1-216-097-91 RES,CHIP 100K 5% 1/10W
(AEP,UK)
R808 1-216-073-00 METAL CHIP 10K 5% 1/10W
R809 1-216-097-91 RES,CHIP 100K 5% 1/10W
R810 1-216-097-91 RES,CHIP 100K 5% 1/10W
R811 1-216-073-00 METAL CHIP 10K 5% 1/10W
R812 1-216-073-00 METAL CHIP 10K 5% 1/10W
R813 1-216-073-00 METAL CHIP 10K 5% 1/10W
R814 1-216-073-00 METAL CHIP 10K 5% 1/10W
R815 1-216-073-00 METAL CHIP 10K 5% 1/10W
R816 1-216-073-00 METAL CHIP 10K 5% 1/10W
R819 1-216-109-00 METAL CHIP 330K 5% 1/10W
R820 1-216-073-00 METAL CHIP 10K 5% 1/10W
