Sony MDS-JB930 - BD Board Parts List; BD Board Components (ICs, Transistors, Coils, Resistors)

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
66
BD
C118 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C119 1-125-822-11 TANTALUM 10uF 20% 10V
C121 1-125-822-11 TANTALUM 10uF 20% 10V
C122 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C123 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C124 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C127 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C128 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C129 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C130 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C131 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C132 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C133 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C134 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C136 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C142 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C143 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C144 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C146 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C152 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C153 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C156 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C158 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-104-601-11 ELECT CHIP 10uF 20% 10V
C161 1-104-601-11 ELECT CHIP 10uF 20% 10V
C163 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C164 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C167 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C168 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C169 1-125-822-11 TANTALUM 10uF 20% 10V
C171 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C181 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
C183 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C184 1-117-970-11 ELECT CHIP 22uF 20% 10V
C185 1-164-611-11 CERAMIC CHIP 0.001uF 10% 500V
C187 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
C188 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C189 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C190 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C191 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C196 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C197 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-569-479-21 CONNECTOR, FPC 21P
CN102 1-784-833-21 CONNECTOR, FFC (LIF(NON-ZIF)) 21P
CN103 1-784-834-21 CONNECTOR, FFC (LIF(NON-ZIF)) 23P
CN104 1-770-687-11 CONNECTOR, FFC/FPC 4P
CN110 1-695-440-21 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D181 8-719-046-86 DIODE F1J6TP
D183 8-719-046-86 DIODE F1J6TP
< IC/TRANSISTOR >
IC101 8-752-080-95 IC CXA2523AR
IC103 8-729-903-10 TRANSISTOR FMW1-T-148
IC121 8-752-390-16 IC CXD2656R
IC123 8-759-096-87 IC TC7WU04FU (TE12R)
IC124 8-759-334-38 IC MSM51V4400-70TS-K
IC152 8-759-430-25 IC BH6511FS-E2
IC171 8-759-487-04 IC BR24C02F-E2
IC181 8-759-481-17 IC MC74ACT08DTR2
IC192 8-759-460-72 IC BA033FP-E2
< COIL/FERRITE BEAD/SHORT >
L101 1-414-813-11 FERRITE 0uH
L102 1-414-813-11 FERRITE 0uH
L103 1-414-813-11 FERRITE 0uH
L105 1-414-813-11 FERRITE 0uH
L106 1-414-813-11 FERRITE 0uH
L121 1-414-813-11 FERRITE 0uH
L122 1-414-813-11 FERRITE 0uH
L151 1-412-029-11 INDUCTOR CHIP 10uH
L152 1-412-029-11 INDUCTOR CHIP 10uH
L153 1-412-032-11 INDUCTOR CHIP 100uH
L154 1-412-032-11 INDUCTOR CHIP 100uH
L161 1-414-813-11 FERRITE 0uH
L162 1-414-813-11 FERRITE 0uH
L181 1-216-295-91 SHORT 0
< TRANSISTOR >
Q101 8-729-028-91 TRANSISTOR RT1P441M-TP-1
Q102 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q103 8-729-028-99 TRANSISTOR RN1307-TE85L
Q103 8-729-028-99 TRANSISTOR DTC114YUT106
Q104 8-729-028-99 TRANSISTOR RN1307-TE85L
Q162 8-729-101-07 TRANSISTOR 2SB798-T1DK
Q163 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q181 8-729-018-75 FET 2SJ278MYTR
Q182 8-729-017-65 FET 2SK1764KYTR
< RESISTOR >
R103 1-216-049-11 RES, CHIP 1K 5% 1/10W
R104 1-216-073-00 METAL CHIP 10K 5% 1/10W
R105 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R106 1-216-133-00 METAL CHIP 3.3M 5% 1/10W
R107 1-216-113-00 METAL CHIP 470K 5% 1/10W
R109 1-216-295-00 SHORT 0
R110 1-216-073-00 METAL CHIP 10K 5% 1/10W
R111 1-216-295-00 SHORT 0
R112 1-216-089-00 RES, CHIP 47K 5% 1/10W
R113 1-216-049-11 RES, CHIP 1K 5% 1/10W
R115 1-216-049-11 RES, CHIP 1K 5% 1/10W
R117 1-216-113-00 METAL CHIP 470K 5% 1/10W
R120 1-216-025-00 RES, CHIP 100 5% 1/10W
R121 1-216-097-00 RES, CHIP 100K 5% 1/10W
R123 1-216-295-00 SHORT 0
R124 1-216-025-00 RES, CHIP 100 5% 1/10W
R125 1-216-025-00 RES, CHIP 100 5% 1/10W
R127 1-216-025-00 RES, CHIP 100 5% 1/10W
R129 1-216-295-00 SHORT 0
