Sony MVC-CD200 Service Manual

5-30
10.White Balance Adjustment (PK-58 board)
Correct the white balance.
If deviated, the LCD screen color cannot be reproduced.
Mode Still (Auto ( ))
Subject Arbitrary
Measurement Point Check on LCD display
Measuring Instrument
Adjustment Page D
Adjustment Address D2, D3
Specified Value The LCD screen should not be colored.
Note1: Use the AC power adaptor during this adjustment.
Note2: Check the white balance only when replacing the following parts.
If necessary, adjust them.
1. LCD panel
2. Light induction plate
3. IC802
Adjusting method:
Order Page Address Data Procedure
1 0 01 01 Set the data.
2 4 F1 02 Set the data.
3 D D2 98 Set the data, and press PAUSE
button.
4 D D3 7A Set the data, and press PAUSE
button.
5 D D3 Check that the LCD screen is not
colored. If not colored, proceed to
step 11.
6 D D2 Change the data so that the LCD
screen is not colored.
7 D D2 Press PAUSE button.
8 D D3 Change the data so that the LCD
screen is not colored.
9 D D3 Press PAUSE button.
10 If the LCD screen is colored,
repeat steps 6 to 10.
11 4 F1 00 Set the data.
12 0 01 00 Set the data.
