Sony MVC-CD200 Service Manual

5-37
6. Switch check (4)
Page 2 Address 90 to 93
Using method:
1) Select page: 2, address: 90 to 93.
2) By discriminating the display data, the pressed key can be
discriminated.
7. Switch check (5)
Page 2 Address 94
Using method:
1) Select page: 2, address: 94.
2) By discriminating the display data, the mode dial position can
be discriminated.
Note: Refer to “Switch check (1)” and “Switch check (2)”.
8. LED check
Page 2 Address 04
Using method:
1) Select page: 2, address: 04, set data: 01 and press PAUSE button.
2) Check that all LED are lit.
3) Select page: 2, address: 04, set data: 00 and press PAUSE button.
Address
90
(KEY AD0)
(IC402 is)
91
(KEY AD1)
(IC402 id)
92
(KEY AD2)
(IC402 if)
93
(KEY AD3)
(IC402 ig)
00 to 14
Control button
DOWN
(S001)(FS-83 board)
Control button
RIGHT
(S001)(FS-83 board)
DISPLAY
(S301)
(PK-58 board)
ZOOM W
(Control switch
block (ZK-503))
15 to 46
Control button
UP
(S001)(FS-83 board)
Control button
LEFT
(S001)(FS-83 board)
AE LOCK
(S303)
(PK-58 board)
ZOOM T
(Control switch
block (ZK-503))
47 to 70
MENU
(S002)
(FS-83 board)
Control button SET
(S001)
(FS-83 board)
EV ( )
(S306)
(PK-58 board)
JOG SET
(Control switch
block (ZK-503))
71 to A5
FOCUS
(S307)
(PK-58 board)
A6 to DE
SPOT METER
( )
(S304)(PK-58 board)
DF to FF
No key input
No key input
No key input
No key input
Data
Address
94
(MODE DIAL)
(IC402 ih)
00 to 14
Mode dial
AE-S
(Control switch
block (ZK-503))
15 to 3D
Mode dial
AE-A
(Control switch
block (ZK-503))
3E to 67
Mode dial
AE-M
(Control switch
block (ZK-503))
68 to 93
Mode dial
SCN
(Control switch
block (ZK-503))
94 to D0
Mode dial
MOVIE (
)
(Control switch
block (ZK-503))
D1 to FF
Mode dial
AUTO ( ) or
PLAY (
) or
SETUP
(Control switch
block (ZK-503))
Note
Data
