1-2. INITIALIZATION OF B, D, E, F, 7, 9 PAGE
DATA
1-2-1. INITIALIZATION OF D PAGE DATA
1. Initializing the D Page Data
Note: If the D page data has been initialized, the following
adjustments need to be performed again.
1) Modification of D page data
2) LCD system adjustments
3) Color viewfinder system adjustments
4) Battery end adjustments
Adjusting page D
Adjusting Address 10 to EF
Initializing Method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 4 03 Set the following data.
12: MVC-CD200
11: MVC-CD300
3 4 00 2D Set the data.
4 4 01 2D Set the data, and press PAUSE
button.
5 4 02 Check that the data changes to
“01”.
6 2 00 29 Set the data.
7 2 01 29 Set the data, and press PAUSE
button.
8 Perform “Modification of D Page
Data”.
2. Modification of D Page Data
If the D page data has been initialized, change the data of the “Fixed
data-2” address shown in the following table by manual input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the camera may
not operate.
3) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
4) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification of D Page data
Order Page
Address
Data Procedure
1 2 00 29 Set the data.
2 2 01 29 Set the data, and press PAUSE
button.
3. D Page Table
Note: Fixed data-1: Initialized data. (Refer to “1. Initializing the D Page
Data”.)
Fixed data-2: Modified data. (Refer to “2. Modification of D Page
Data”.)
Table. 5-1-2.
00 to 0F
10
11 to 4D
4F
50 to 8F
90
91
92
93
94
95 to B5
B6
B7
B8 to C5
C6
C7
C8 to CD
CE
CF
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
DA to DB
DC
DD
DE
DF
E0 to EB
EC
ED
EE
EF
00
86
8E
9D
B2
BD
1D
09
5A
61
BA
B8
AA
66
98
7A
B8
B0
7C
6F
74
73
B5
6F
9A
B8
00
00
00
00
Test mode
Fixed data-1
Fixed data-2
Fixed data-1
Battery end adj.
Fixed data-1
Battery end adj.
Fixed data-1
Video output level adj.
Fixed data-1
Bright adj. (LCD)
Contrast adj. (LCD)
Bright adj. (LCD)
Color adj. (LCD)
White balance adj.
Contrast adj. (LCD)
D range adj. (LCD)
V-COM level adj. (LCD)
VCO adj. (NTSC) (LCD)
V COM adj. (LCD)
Fixed data
Fixed data-1
Fixed data
VCO adj. (PAL) (LCD)
Bright adj. (LCD)
Contrast adj. (LCD)
Fixed data-1
Recording counter
Address Remark
Initial value
To Next Page
