4-74
MVC-CD200/CD300
4.5Vp-p
4.5Vp-p
0.2Vp-p
H
0.2Vp-p
H
0.5Vp-p
H
4.5Vp-p
2H
2H
2H
1
IC302 8
3
IC302 q;
4
IC302 w;
5
IC302 ws
2
IC302 9
6
IC302 wf
PK-58
BOARD
WAVEFORMS
PK-58
