2-8. CIRCUIT BOARDS LOCATION
DD-119 BOARD
(DC/DC CONVERTER)
MF BLOCK (50080)
FLASH UNIT
RL-51
(MIC AMP)
CD-206
(CCD IMAGER)
PK-44
REC/PB AMP, LCD DRIVE,
TIMING GENERATOR,
BACK-LIGHT DRIVE,
MODE KEY SWITCH
FC-67
CAMERA Y/C PROCESS,
DRAM CONTROL, LENS MOTOR DRIVE,
D/A CONVERTER, AUDIO A/D.D/A CONVERTER,
FD/SYSTEM CONTROL, HI CONTROL
FP-65
(FC-67 – PK-44 CONNECTOR)
(From LENS BLOCK)
FP-66
(CD-206 – FC-67 CONNECTOR)
(From FLOPPY DISK DRIVE)
(From FLOPPY DISK DRIVE)
