Sony MVC-FD81 - LCD Block Diagram

MVC-FD81
3-4. LCD BLOCK DIAGRAM
3-11 3-12
78µsec
0.18Vp-p
IC802 8
0.16Vp-p
78µsec
IC802 9
IC802 !º
0.1Vp-p
78µsec
IC802 @º
4Vp-p
156µsec
IC802 @™
4Vp-p
156µsec
IC802 @¢
4Vp-p
156µsec
IC903 1
3.3Vp-p
20msec
IC903 4
3.3Vp-p
78µsec
IC901 @§
4.5Vp-p
150nsec
IC901 #¶
3.3Vp-p
78µsec
IC902 7
5.6Vp-p
156µsec
