6-5
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< CONNECTOR >
CN301 1-580-057-11 PIN, CONNECTOR 4P
* CN302 1-778-011-42 CONNECTOR, BOARD TO BOARD 50P
< DIODE >
D304 8-719-027-76 DIODE 1SS357-TPH3
D305 8-719-027-77 DIODE MA796-TX
D306 8-719-404-49 DIODE MA111-TX
D307 8-719-404-49 DIODE MA111-TX
< FUSE >
! F301 1-533-709-11 FUSE (SMD) (1.25A/24V)
! F302 1-533-709-11 FUSE (SMD) (1.25A/24V)
! F303 1-533-709-11 FUSE (SMD) (1.25A/24V)
! F304 1-533-709-11 FUSE (SMD) (1.25A/24V)
< IC >
IC301 8-759-060-94 IC MB3785APFV-G-BND-ER
< COIL >
L301 1-416-344-11 INDUCTOR 10uH
L302 1-416-344-11 INDUCTOR 10uH
L303 1-416-345-11 INDUCTOR 22uH
L304 1-416-345-11 INDUCTOR 22uH
L305 1-416-345-11 INDUCTOR 22uH
L306 1-414-396-21 INDUCTOR 4.7uH
L307 1-414-392-21 INDUCTOR 1uH
L308 1-414-396-21 INDUCTOR 4.7uH
L309 1-414-406-11 INDUCTOR 220uH
L310 1-414-396-21 INDUCTOR 4.7uH
L311 1-414-396-21 INDUCTOR 4.7uH
L312 1-414-396-21 INDUCTOR 4.7uH
L315 1-414-396-21 INDUCTOR 4.7uH
L316 1-416-344-11 INDUCTOR 10uH
L317 1-414-392-21 INDUCTOR 1uH
< LINE FILTER >
LF301 1-411-957-11 FILTER, COMMON MODE
< TRANSISTOR >
Q306 8-729-033-14 TRANSISTOR FP107-TL
Q307 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q308 8-729-033-14 TRANSISTOR FP107-TL
Q309 8-729-033-14 TRANSISTOR FP107-TL
Q310 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q311 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q312 8-729-041-23 TRANSISTOR NDS356AP
Q313 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q314 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q315 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q316 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q317 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q318 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q319 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q320 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q321 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q322 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q323 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q324 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q325 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q326 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q327 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR(TPL3)
Q328 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q329 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q330 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
< RESISTOR >
R309 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R310 1-216-850-11 METAL CHIP 270K 5% 1/16W
R312 1-216-864-11 METAL CHIP 0 5% 1/16W
R314 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R315 1-218-879-11 RES,CHIP 22K 0.50% 1/16W
R316 1-218-852-11 RES,CHIP 1.6K 0.50% 1/16W
R317 1-218-863-11 RES,CHIP 4.7K 0.50% 1/16W
R318 1-216-840-11 METAL CHIP 39K 5% 1/16W
R319 1-216-838-11 METAL CHIP 27K 5% 1/16W
R320 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R321 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R324 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R325 1-218-837-11 RES,CHIP 390 0.50% 1/16W
R326 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R327 1-216-847-11 METAL CHIP 150K 5% 1/16W
R328 1-216-833-11 METAL CHIP 10K 5% 1/16W
R330 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R331 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R332 1-216-864-11 METAL CHIP 0 5% 1/16W
R333 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R334 1-216-841-11 METAL CHIP 47K 5% 1/16W
R335 1-216-843-11 METAL CHIP 68K 5% 1/16W
R336 1-216-821-11 METAL CHIP 1K 5% 1/16W
R337 1-216-821-11 METAL CHIP 1K 5% 1/16W
R340 1-218-861-11 RES,CHIP 3.9K 0.50% 1/16W
R341 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R342 1-218-863-11 RES,CHIP 4.7K 0.50% 1/16W
R343 1-216-833-11 METAL CHIP 10K 5% 1/16W
R346 1-216-813-11 METAL CHIP 220 5% 1/16W
R347 1-216-819-11 METAL CHIP 680 5% 1/16W
R348 1-216-817-11 METAL CHIP 470 5% 1/16W
R349 1-216-817-11 METAL CHIP 470 5% 1/16W
R352 1-216-845-11 METAL CHIP 100K 5% 1/16W
R353 1-216-845-11 METAL CHIP 100K 5% 1/16W
R356 1-216-845-11 METAL CHIP 100K 5% 1/16W
R357 1-216-841-11 METAL CHIP 47K 5% 1/16W
R358 1-216-837-11 METAL CHIP 22K 5% 1/16W
R360 1-218-883-11 RES,CHIP 33K 0.50% 1/16W
R361 1-216-864-11 METAL CHIP 0 5% 1/16W
R362 1-218-897-11 RES,CHIP 120K 0.50% 1/16W
R363 1-218-897-11 RES,CHIP 120K 0.50% 1/16W
R364 1-216-864-11 METAL CHIP 0 5% 1/16W
R365 1-216-835-11 METAL CHIP 15K 5% 1/16W
R366 1-216-845-11 METAL CHIP 100K 5% 1/16W
R367 1-216-841-11 METAL CHIP 47K 5% 1/16W
DD-119
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
