6-8
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
FB486 1-414-228-11 INDUCTOR CHIP 0UH
FB487 1-414-228-11 INDUCTOR CHIP 0UH
FB488 1-414-228-11 INDUCTOR CHIP 0UH
FB489 1-414-228-11 INDUCTOR CHIP 0UH
* FB490 1-216-797-11 METAL CHIP 10 5% 1/16W
(Note 1)
* FB491 1-216-797-11 METAL CHIP 10 5% 1/16W
(Note 1)
FB801 1-414-233-21 INDUCTOR CHIP 0UH
FB802 1-414-228-11 INDUCTOR CHIP 0UH
FB803 1-414-228-11 INDUCTOR CHIP 0UH
< IC >
IC001 8-759-547-46 IC MSM9831-SGX4880MAZ060
IC002 8-759-075-66 IC TA75S01F(TE85R)
IC003 8-759-075-66 IC TA75S01F(TE85R)
IC004 8-759-566-19 IC AK4518VF-E2
IC006 8-759-494-52 IC BA7783FS-E2
IC101 8-759-526-24 IC CCD1000Y/T2
IC102 8-752-395-77 IC CXD2457R-T4
IC103 8-752-395-76 IC CXD3135R-T6
IC104 8-759-447-94 IC NJU7201U32-TE1
IC401 8-759-337-40 IC NJM2904V(TE2)
IC402 8-759-475-79 IC uPD16833AG3-E2
IC403 8-752-377-38 IC CXD2430N-T4
IC404 8-759-338-78 IC BA10324AFV-E2
IC405 8-759-075-66 IC TA75S01F(TE85R)
IC451 8-759-543-83 IC KM416V1204CT-L6T
IC452 8-759-543-83 IC KM416V1204CT-L6T
IC453 8-752-395-40 IC CXD3138R
IC481 8-759-564-51 IC KZ4E063G21WFP
IC601 8-752-384-33 IC CXD3121R-T4
IC701 8-759-298-10 IC S-8423NFS-T2
IC702 8-759-572-78 IC S579291PZ-TEB
IC703 8-759-445-94 IC AK6480AM-E2
IC704 8-759-364-05 IC M62376GP-65AD
IC705 8-759-574-31 IC MB90097PFV-G-116-BND-ER
IC801 8-759-458-76 IC uPD72069GF-3BA
IC802 8-759-196-97 IC TC7SH32FU-TE85R
IC803 8-759-466-32 IC TA8563FN(EL)
IC804 8-759-475-48 IC TC74LCX245FT(EL)
IC805 8-759-083-94 IC TC7W74FU(TE12R)
IC851 8-759-564-97 IC HD6417708SF60
IC852 8-759-565-13 IC MBM29LV200B-10PFTN-025-ER
< COIL >
L001 1-414-754-11 INDUCTOR 10uH
L002 1-414-754-11 INDUCTOR 10uH
L003 1-414-406-11 INDUCTOR 220uH
L004 1-414-754-11 INDUCTOR 10uH
L005 1-414-754-11 INDUCTOR 10uH
L007 1-414-754-11 INDUCTOR 10uH
L101 1-414-754-11 INDUCTOR 10uH
L102 1-414-754-11 INDUCTOR 10uH
L103 1-414-754-11 INDUCTOR 10uH
L104 1-414-754-11 INDUCTOR 10uH
L401 1-414-078-11 INDUCTOR 10uH
L402 1-414-754-11 INDUCTOR 10uH
L403 1-414-078-11 INDUCTOR 10uH
L451 1-414-402-11 INDUCTOR 47uH
L452 1-414-402-11 INDUCTOR 47uH
L601 1-412-951-11 INDUCTOR 10uH
L602 1-412-963-21 INDUCTOR 100uH
L603 1-412-963-21 INDUCTOR 100uH
L604 1-412-963-21 INDUCTOR 100uH
L701 1-414-754-11 INDUCTOR 10uH
L702 1-414-757-11 INDUCTOR 100uH
L703 1-414-757-11 INDUCTOR 100uH
L801 1-414-754-11 INDUCTOR 10uH
L802 1-414-402-11 INDUCTOR 47uH
L803 1-414-402-11 INDUCTOR 47uH
< TRANSISTOR >
Q101 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q102 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q103 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q104 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q401 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q402 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q403 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q601 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q602 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q603 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q701 8-729-024-48 TRANSISTOR 2SK1830-TE85L
Q702 8-729-032-62 TRANSISTOR 2SJ347-TE85L
Q703 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q704 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q705 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q706 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q707 8-729-037-52 TRANSISTOR 2SD2216J-QR(TX).SO
Q708 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q801 8-729-037-61 TRANSISTOR RN2104F(TPL3)
Q802 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q803 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q804 8-729-037-53 TRANSISTOR 2SB1462J-QR(TX).SO
Q805 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q1005 8-729-015-66 TRANSISTOR 2SC4919
< RESISTOR >
R007 1-216-864-11 METAL CHIP 0 5% 1/16W
R008 1-216-852-11 METAL CHIP 390K 5% 1/16W
R009 1-216-833-11 METAL CHIP 10K 5% 1/16W
R010 1-216-837-11 METAL CHIP 22K 5% 1/16W
R011 1-216-821-11 METAL CHIP 1K 5% 1/16W
R012 1-216-833-11 METAL CHIP 10K 5% 1/16W
R014 1-216-838-11 METAL CHIP 27K 5% 1/16W
R016 1-216-844-11 METAL CHIP 82K 5% 1/16W
R017 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R019 1-216-851-11 METAL CHIP 330K 5% 1/16W
R020 1-216-848-11 METAL CHIP 180K 5% 1/16W
R021 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R022 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R024 1-216-817-11 METAL CHIP 470 5% 1/16W
R025 1-216-864-11 METAL CHIP 0 5% 1/16W
FC-67
Note 1: Resistors are mounted to the location where FB490, FB491
are printed.
