Applying Special Effects (Edge Effects) 183
No.
Parameter
Adjustment
1
H
Horizontal position
2
V
Vertical position
3
Size
Pattern size
4
Soft
Pattern softness
5
Pattern
Pattern number
Chapter
10
DME
Operations
Replicating the wipe crop pattern
(Multiplication)
1 In the Wipe Crop menu (4116), press [Multi], turning
it on.
2 Set the following parameters.
No.
Parameter
Adjustment
1
H Multi
Number of repetitions of pattern
horizontally
2
V Multi
Number of repetitions of pattern
vertically
3
Invert Type
Replication layout
a)
a) 1 p. 105
Modifying the wipe crop pattern edge
You can apply a border to the wipe crop pattern, or soften
the boundary.
1 In the <Edge> group of the Wipe Crop menu (4116),
select one of the following.
Border: Border
Soft: Soft edge
Soft Border: Soft border
2 Depending on the selection in step 1, adjust the
following parameters.
When Border is selected
No.
Parameter
Adjustment
1
Width
Border width
When Soft is selected
No.
Parameter
Adjustment
1
Soft
Edge softness
When Soft Border is selected
No.
Parameter
Adjustment
1
Width
Border width
2
Inner Soft
Border inner softness
3
Outer Soft
Border outer softness
Selecting the signal or color to be inserted
in the wipe crop border
When you are applying a border or soft border to the wipe
crop, you can select the signal or color to be inserted in the
border.
1 In the <Border Fill> group of the Wipe Crop menu
(4116), select one of the following.
Flat Color: Single color
Mix Color: A mix color signal combining color 1 and
color 2.
For details, 1 “Color Mix Settings” (p. 183).
Ext Video: An external video signal input to the Ext
IN connector
2 If [Flat Color] is selected in step 1, adjust the
following parameters.
No.
Parameter
Adjustment
1
Luminance
Luminance
2
Saturation
Saturation
3
Hue
Hue
Color Mix Settings
Notes
The color mix function is not supported by the MKS-6570
or MVE-8000A.
Creating a color combination pattern
To select the pattern
1 Open the DME >Edge >Color Mix menu (4117).
2 Press [Mix Pattern Select].
The Mix Pattern Select menu (4117.1) appears.
3 From the displayed patterns (wipe patterns 1 to 24),
press any pattern to select it.
In this state, you can adjust the pattern size and border
softness (see the next item).
To set the pattern size and position
1 In the Color Mix menu (4117), press [Position/Size].
2 Set the following parameters.
