Sony MXD-D3 - Page 56

5656
MXD-D3
• Waveforms
– BD (CD) Board –
1 IC131 qh (RFO) (PLAY MODE)
2 IC101 ra (TE) (PLAY MODE)
3 IC101 el (FE) (PLAY MODE)
6 IC101 q; (WFCK)
Approx.
1.2 Vp-p
Approx.
0.2 Vp-p
Approx.
0.2 Vp-p
5.8 Vp-p
22.8
µ
s
5.8 Vp-p
472
µ s
5.8 Vp-p
136
µ s
0.46 Vp-p
0.1 Vp-p
0.06Vp-p
48.8 Vp-p
11 ms
4.6 Vp-p
44.1 kHz
4.8 Vp-p
2.8224 MHz
4.7 Vp-p
11.29 MHz
4.6 Vp-p
176.4 kHz
5 IC101 yj (BCLK)
4 IC101 yg (LRCK)
2 IC101 4 (A) (MD PLAY)
3 IC101 8, 9 (E, F) (MD PLAY)
5 IC121 wj (LRCK)
4 IC121 qh (OSCI)
– BD (MD) Board –
1 IC101 1, 2 (I, J) (MD PLAY)
7 IC121 wl (FS256)
8 IC121 o; (FS4)
6 IC121 wk (XBCK)
2 IC601 qg (XIN)
3 IC601 ed (SCLK)
5 IC401 9 (XTI)
4 IC601 ej (FLCLK)
– MAIN Board –
1 IC501 qs (XIN) (CD PLAY)
1.8 Vp-p
22.5 MHz
3.2 Vp-p
357 kHz
3.2 Vp-p
1.66 MHz
2.6 Vp-p
10 MHz
4.3 Vp-p
10 MHz
6 IC401 qa (LRCK)
4.3 Vp-p
44.1 kHz
7 IC401 qs (BCLK)
4.3 Vp-p
2.822 MHz
8 IC607 qf (4A)
4.9 Vp-p
2.822 MHz
9 IC605 qs
6.3 Vp-p
44.1 kHz
0 IC503 qd
4.6 Vp-p
11.29 MHz
qa IC604 1
4.9 Vp-p
22.578 MHz
qs IC603 8 (2-Q)
6.8 Vp-p
11.29 MHz
qd IC603 qa (2CK)
4.1 Vp-p
22.579 MHz
qf IC606 8
4.6 Vp-p
2.117 MHz
– DISPLAY Board –
1 IC751 yg (OSCI)
1.7 Vp-p
2.137 MHz
qg IC606 qa
4.2 Vp-p
44.1 kHz
