Sony MXD-D3 - ELECTRICAL PARTS LIST; Component Lists by Board

79
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD (CD)
A-4724-886-A BD (CD) BOARD, COMPLETE
***********************
< CAPACITOR >
C1 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C10 1-107-812-11 TANTALUM CHIP 4.7uF 20% 6.3V
C39 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C42 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C101 1-135-155-21 TANTALUM CHIP 4.7uF 10% 16V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C105 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C106 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C107 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C108 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C112 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C113 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C114 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C115 1-113-503-11 CERAMIC CHIP 0.0039uF 5% 25V
C116 1-163-127-00 CERAMIC CHIP 270PF 5% 50V
C117 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C119 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C131 1-135-216-11 TANTALUM CHIP 10uF 20% 10V
C132 1-126-209-11 ELECT CHIP 100uF 20% 4V
C133 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C134 1-126-607-11 ELECT CHIP 47uF 20% 4V
C135 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C136 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C137 1-164-346-11 CERAMIC CHIP 1uF 16V
C138 1-164-346-11 CERAMIC CHIP 1uF 16V
C142 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C143 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C145 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C146 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C147 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C148 1-126-607-11 ELECT CHIP 47uF 20% 4V
C171 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C172 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C173 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C174 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C175 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C176 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C179 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C181 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C184 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C185 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C187 1-163-018-00 CERAMIC CHIP 0.0056uF 5% 50V
C191 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C199 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C221 1-135-155-21 TANTALUM CHIP 4.7uF 10% 16V
C222 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C283 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C297 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P
CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P
* CN103 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< IC >
IC101 8-752-389-34 IC CXD2585Q
IC115 8-759-082-61 IC TC4W53FU (TE12R)
IC131 8-752-085-51 IC CXA2568M-T6
IC171 8-759-549-28 IC BA5974FP-E2
IC181 8-759-058-43 IC NJM3404AV (TE2)
IC182 8-759-448-71 IC BU4053BCFV-E2
IC191 8-759-335-52 IC BA6195FP-YT2
< TRANSISTOR >
Q131 8-729-010-08 TRANSISTOR MSB710-RT1
< RESISTOR >
R1 1-216-103-00 METAL CHIP 180K 5% 1/10W
R4 1-216-103-00 METAL CHIP 180K 5% 1/10W
R42 1-216-077-11 RES, CHIP 15K 5% 1/10W
R51 1-216-295-00 SHORT 0
R61 1-216-295-00 SHORT 0
R102 1-216-295-00 SHORT 0
R103 1-216-049-11 RES, CHIP 1K 5% 1/10W
R104 1-216-097-00 RES, CHIP 100K 5% 1/10W
R106 1-216-077-11 RES, CHIP 15K 5% 1/10W
R107 1-216-097-00 RES, CHIP 100K 5% 1/10W
R108 1-216-077-11 RES, CHIP 15K 5% 1/10W
R111 1-216-085-00 METAL CHIP 33K 5% 1/10W
R112 1-216-073-00 METAL CHIP 10K 5% 1/10W
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark 0
are critical for safety.
Replace only with part number
specified.
