Sony MXD-D3 - Components Identified by Mark 0 or Dotted

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
85
<TERMINAL>
EPT901 1-537-770-21 TERMINAL BOARD, GROUND
< FERRITE BEAD/SHORT >
FB500 1-216-295-00 SHORT 0
FB501 1-216-295-00 SHORT 0
FB502 1-216-295-00 SHORT 0
FB681 1-414-235-22 INDUCTOR CHIP 0UH
FB682 1-414-235-22 INDUCTOR CHIP 0UH
< IC >
IC201 8-759-100-96 IC NJM4558M-T2
IC301 8-759-100-96 IC NJM4558M-T2
IC401 8-759-584-26 IC AK4524-TP
IC402 8-759-708-05 IC NJM78L05A-T3
IC403 8-759-100-96 IC NJM4558M-T2
IC451 8-759-100-96 IC NJM4558M-T2
IC501 8-759-644-36 IC M30625MGA-A50GP
IC502 8-759-822-09 IC LB1641
IC503 8-759-269-92 IC SN74HCU04ANSR
IC601 8-759-638-23 IC M30624MG-A10FP
IC602 8-759-481-19 IC LB1830M-S-TE-L
IC603 8-759-099-37 IC SN74HCT74ANSR
IC604 8-759-269-92 IC SN74HCU04ANSR
IC605 8-759-548-61 IC SN74LV08ANSR
IC606 8-759-548-61 IC SN74LV08ANSR
IC607 8-759-926-18 IC SN74HC157ANSR
IC608 8-759-269-92 IC SN74HCU04ANSR
IC609 8-749-012-70 IC GP1F38R (DIGITAL OPTICAL IN)
IC901 8-759-701-75 IC NJM7805FA
IC902 8-759-701-75 IC NJM7805FA
IC903 8-759-604-32 IC M5F7810L
IC904 8-759-450-49 IC BA07T
IC905 8-759-486-55 IC NJM2370U33-TE2
IC906 8-759-481-02 IC M62016L
IC941 8-759-633-42 IC M5293L
< JACK >
J401 1-784-429-11 JACK, PIN 4P (LINE (ANALOG) IN/OUT)
< COIL >
L401 1-412-056-11 INDUCTOR CHIP 4.7uH
L501 1-408-958-21 INDUCTOR 1uH
L502 1-410-369-11 INDUCTOR 1uH
L503 1-408-958-21 INDUCTOR 1uH
L504 1-408-958-21 INDUCTOR 1uH
L652 1-410-377-31 INDUCTOR CHIP 4.7uH
L653 1-412-056-11 INDUCTOR CHIP 4.7uH
L654 1-412-006-31 INDUCTOR CHIP 10uH (US, Canadian)
< TRANSISTOR >
Q221 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX). SO
Q321 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX). SO
Q401 8-729-424-08 TRANSISTOR UN2111-TX
Q451 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX). SO
Q452 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX). SO
Q501 8-729-421-19 TRANSISTOR UN2213-TX
Q651 8-729-421-22 TRANSISTOR UN2211-TX
Q951 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
< RESISTOR >
R11 1-216-295-00 SHORT 0
R12 1-216-295-00 SHORT 0
R13 1-216-295-00 SHORT 0
R14 1-216-033-00 RES, CHIP 220 5% 1/10W
R15 1-216-033-00 RES, CHIP 220 5% 1/10W
R16 1-216-033-00 RES, CHIP 220 5% 1/10W
R201 1-216-687-11 METAL CHIP 33K 0.5% 1/10W
R202 1-216-679-11 METAL CHIP 15K 0.5% 1/10W
R203 1-218-764-11 RES, CHIP 330K 5% 1/10W
R204 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R221 1-216-639-11 METAL CHIP 330 0.5% 1/10W
R222 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R223 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R224 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R225 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R226 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R227 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R228 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R229 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R230 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R231 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R232 1-219-786-11 FUSIBLE 22 5% 1/4W
R233 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R301 1-216-687-11 METAL CHIP 33K 0.5% 1/10W
R302 1-216-679-11 METAL CHIP 15K 0.5% 1/10W
R303 1-218-764-11 RES, CHIP 330K 5% 1/10W
R304 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R321 1-216-639-11 METAL CHIP 330 0.5% 1/10W
0 R322 1-216-647-11 METAL CHIP 680 0.5% 1/10W F
R323 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R324 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R325 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R326 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R327 1-216-683-11 METAL CHIP 22K 0.5% 1/10W
R328 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R329 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R330 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
R331 1-216-675-11 METAL CHIP 10K 0.5% 1/10W
0 R332 1-219-786-11 FUSIBLE 22 5% 1/4W F
R333 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R401 1-216-295-00 SHORT 0
R402 1-216-017-91 RES, CHIP 47 5% 1/10W
R403 1-216-017-91 RES, CHIP 47 5% 1/10W
R404 1-216-017-91 RES, CHIP 47 5% 1/10W
R405 1-216-017-91 RES, CHIP 47 5% 1/10W
R406 1-216-101-00 METAL CHIP 150K 5% 1/10W
R407 1-216-025-00 RES, CHIP 100 5% 1/10W
R408 1-216-025-00 RES, CHIP 100 5% 1/10W
R409 1-216-025-00 RES, CHIP 100 5% 1/10W
R451 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R452 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R453 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R454 1-216-619-11 METAL CHIP 47 0.5% 1/10W
R455 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
MAIN
