Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
80
R113 1-216-097-00 RES, CHIP 100K 5% 1/10W
R114 1-216-025-00 RES, CHIP 100 5% 1/10W
R116 1-216-073-00 METAL CHIP 10K 5% 1/10W
R117 1-216-049-11 RES, CHIP 1K 5% 1/10W
R118 1-216-073-00 METAL CHIP 10K 5% 1/10W
R119 1-216-121-00 RES, CHIP 1M 5% 1/10W
R121 1-216-037-00 RES, CHIP 330 5% 1/10W
R122 1-216-001-00 RES, CHIP 10 5% 1/10W
R123 1-216-001-00 RES, CHIP 10 5% 1/10W
R124 1-216-001-00 RES, CHIP 10 5% 1/10W
R125 1-216-073-00 METAL CHIP 10K 5% 1/10W
R129 1-216-295-00 SHORT 0
R132 1-216-001-00 METAL CHIP 10 5% 1/10W
R133 1-216-003-11 RES, CHIP 12 5% 1/10W
R138 1-216-103-00 METAL CHIP 180K 5% 1/10W
R139 1-216-103-00 METAL CHIP 180K 5% 1/10W
R142 1-216-073-00 METAL CHIP 10K 5% 1/10W
R144 1-216-121-00 RES, CHIP 1M 5% 1/10W
R146 1-216-121-00 RES, CHIP 1M 5% 1/10W
R169 1-216-295-00 SHORT 0
R172 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R181 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R182 1-216-085-00 RES, CHIP 33K 5% 1/10W
R184 1-216-097-00 RES, CHIP 100K 5% 1/10W
R185 1-216-105-00 RES, CHIP 220K 5% 1/10W
R187 1-216-101-00 METAL CHIP 150K 5% 1/10W
R193 1-216-073-00 METAL CHIP 10K 5% 1/10W
R195 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R196 1-216-073-00 METAL CHIP 10K 5% 1/10W
R197 1-216-073-00 METAL CHIP 10K 5% 1/10W
R200 1-216-295-00 SHORT 0
R201 1-216-295-00 SHORT 0
R210 1-216-073-00 METAL CHIP 10K 5% 1/10W
R211 1-216-073-00 METAL CHIP 10K 5% 1/10W
R283 1-216-113-00 METAL CHIP 470K 5% 1/10W
R284 1-216-117-00 METAL CHIP 680K 5% 1/10W
R285 1-216-109-00 RES, CHIP 330K 5% 1/10W
R292 1-216-117-00 METAL CHIP 680K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (1KEY) (LIMIT)
**************************************************************
A-4724-855-A BD (MD) BOARD, COMPLETE
************************
< CAPACITOR >
C101 1-125-822-11 TANTALUM 10uF 20% 10V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-125-822-11 TANTALUM 10uF 20% 10V
C104 1-125-822-11 TANTALUM 10uF 20% 10V
C105 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C106 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C107 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C108 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C109 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C111 1-164-344-11 CERAMIC CHIP 0.068uF 10% 25V
C112 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C113 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C115 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C116 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C118 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C119 1-125-822-11 TANTALUM 10uF 20% 10V
C121 1-125-822-11 TANTALUM 10uF 20% 10V
C122 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C123 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C124 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C127 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C128 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C129 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C130 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C131 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C132 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C133 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C134 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C135 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C136 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C139 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C142 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C143 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C144 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C151 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C152 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C153 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C156 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C158 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-104-601-11 ELECT CHIP 10uF 20% 10V
C161 1-104-601-11 ELECT CHIP 10uF 20% 10V
C163 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C164 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C167 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C168 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C169 1-125-822-11 TANTALUM 10uF 20% 10V
C171 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C181 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
C183 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C184 1-117-970-11 ELECT CHIP 22uF 20% 10V
C185 1-128-795-11 ELECT CHIP 470PF 10% 630V
C187 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
C188 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C189 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C190 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C191 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C197 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C198 1-104-913-11 TANTALUM CHIP 10uF 20% 16V
C199 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-569-479-21 CONNECTOR, FPC 21P
CN102 1-784-835-21 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
CN103 1-784-834-21 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
CN104 1-770-687-11 CONNECTOR, FFC/FPC 4P
CN110 1-695-440-21 PIN, CONNECTOR (PC BOARD) 6P
BD (CD) BD (MD)
