Sony MXD-D3 - Page 81

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
81
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D181 8-719-046-86 DIODE F1J6TP
D183 8-719-046-86 DIODE F1J6TP
< IC/TRANSISTOR >
IC101 8-752-080-95 IC CXA2523AR
IC103 8-729-903-10 TRANSISTOR FMW1-T-148
IC121 8-752-390-16 IC CXD2656AR
IC124 8-759-599-51 IC MSM51V17400D-50TS-K
IC152 8-759-430-25 IC BH6511FS-E2
IC171 8-759-487-04 IC BR24C02F-E2
IC181 8-759-481-17 IC MC74ACT08DTR2
IC192 8-759-460-72 IC BA033FP-E2
< COIL/FERRITE BEAD/SHORT >
L101 1-414-813-11 FERRITE 0uH
L102 1-414-813-11 FERRITE 0uH
L103 1-414-813-11 FERRITE 0uH
L105 1-414-813-11 FERRITE 0uH
L106 1-414-813-11 FERRITE 0uH
L121 1-414-813-11 FERRITE 0uH
L122 1-414-813-11 FERRITE 0uH
L151 1-412-029-11 INDUCTOR CHIP 10uH
L152 1-412-029-11 INDUCTOR CHIP 10uH
L153 1-412-032-11 INDUCTOR CHIP 100uH
L154 1-412-032-11 INDUCTOR CHIP 100uH
L161 1-414-813-11 FERRITE 0uH
L162 1-414-813-11 FERRITE 0uH
L181 1-216-295-00 SHORT 0
< TRANSISTOR >
Q101 8-729-403-35 TRANSISTOR UN5113-TX
Q102 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q103 8-729-402-93 TRANSISTOR UN5214-TX
Q104 8-729-402-93 TRANSISTOR UN5214-TX
Q162 8-729-101-07 TRANSISTOR 2SB798-T1DK
Q163 8-729-403-35 TRANSISTOR UN5113-TX
Q181 8-729-048-87 FET 2SJ518AZTR
Q182 8-729-048-88 FET 2SK2788VYTR
< RESISTOR/FERRITE BEAD >
R103 1-216-049-11 RES, CHIP 1K 5% 1/10W
R104 1-216-073-00 METAL CHIP 10K 5% 1/10W
R105 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R106 1-216-133-00 METAL CHIP 3.3M 5% 1/10W
R107 1-216-113-00 METAL CHIP 470K 5% 1/10W
R108 1-216-017-00 RES, CHIP 47 5% 1/10W
R109 1-216-295-00 SHORT 0
R110 1-216-081-00 METAL CHIP 22K 5% 1/10W
R111 1-216-295-00 SHORT 0
R112 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R113 1-216-049-11 RES, CHIP 1K 5% 1/10W
R114 1-216-295-00 SHORT 0
R115 1-216-049-11 RES, CHIP 1K 5% 1/10W
R116 1-216-295-00 SHORT 0
R117 1-216-113-00 METAL CHIP 470K 5% 1/10W
R119 1-216-295-00 SHORT 0
R120 1-216-025-00 RES, CHIP 100 5% 1/10W
R121 1-216-097-00 RES, CHIP 100K 5% 1/10W
R123 1-216-295-00 SHORT 0
R124 1-216-025-00 RES, CHIP 100 5% 1/10W
R125 1-216-025-00 RES, CHIP 100 5% 1/10W
R126 1-414-235-22 FERRITE BEAD 0
R130 1-216-295-00 SHORT 0
R131 1-216-073-00 METAL CHIP 10K 5% 1/10W
R132 1-216-097-00 RES, CHIP 100K 5% 1/10W
R133 1-216-117-00 METAL CHIP 680K 5% 1/10W
R134 1-216-049-11 RES, CHIP 1K 5% 1/10W
R135 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R136 1-216-049-11 RES, CHIP 1K 5% 1/10W
R137 1-216-295-00 SHORT 0
R140 1-216-029-00 METAL CHIP 150 5% 1/10W
R142 1-216-073-00 METAL CHIP 10K 5% 1/10W
R143 1-216-073-00 METAL CHIP 10K 5% 1/10W
R144 1-216-025-00 RES, CHIP 100 5% 1/10W
R145 1-216-073-00 METAL CHIP 10K 5% 1/10W
R146 1-216-037-00 METAL CHIP 330 5% 1/10W
R147 1-216-025-00 RES, CHIP 100 5% 1/10W
R148 1-216-045-00 METAL CHIP 680 5% 1/10W
R149 1-216-073-00 METAL CHIP 10K 5% 1/10W
R150 1-216-295-00 SHORT 0
R151 1-216-073-00 METAL CHIP 10K 5% 1/10W
R152 1-216-073-00 METAL CHIP 10K 5% 1/10W
R153 1-216-033-00 RES, CHIP 220 5% 1/10W
R158 1-216-097-00 RES, CHIP 100K 5% 1/10W
R159 1-216-097-00 RES, CHIP 100K 5% 1/10W
R160 1-216-295-00 SHORT 0
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R163 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R164 1-216-045-00 METAL CHIP 680 5% 1/10W
R165 1-216-097-00 RES, CHIP 100K 5% 1/10W
R166 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R167 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R169 1-219-724-11 METAL CHIP 1 1% 1/4W
R170 1-216-073-00 METAL CHIP 10K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R175 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R177 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R179 1-216-085-00 METAL CHIP 33K 5% 1/10W
R180 1-216-073-00 METAL CHIP 10K 5% 1/10W
R182 1-216-089-00 RES, CHIP 47K 5% 1/10W
R183 1-216-089-00 RES, CHIP 47K 5% 1/10W
R184 1-216-073-00 METAL CHIP 10K 5% 1/10W
R185 1-216-081-00 METAL CHIP 22K 5% 1/10W
R186 1-216-089-00 RES, CHIP 47K 5% 1/10W
R188 1-216-073-00 METAL CHIP 10K 5% 1/10W
R189 1-216-073-00 METAL CHIP 10K 5% 1/10W
R190 1-216-073-00 METAL CHIP 10K 5% 1/10W
R195 1-216-073-00 METAL CHIP 10K 5% 1/10W
R196 1-216-295-00 SHORT 0
R197 1-216-295-00 SHORT 0
R198 1-216-296-00 SHORT 0
BD (MD)
