Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
82
< SWITCH >
S101 1-762-596-21 SWITCH, PUSH (1 KEY) (LIMIT)
S102 1-762-148-21 SWITCH, PUSH (2 KEY)
(REFLECT RATE DETECT, PROTECT DETECT)
< VIBRATOR >
X102 1-781-569-21 OSCILLATOR, CRYSTAL (90.3168MHz)
******************** **************************************
A-4724-857-A DISPLAY BOARD, COMPLETE
(EXCEPT US, Canadian)
A-4725-025-A DISPLAY BOARD, COMPLETE (US, Canadian)
************************
* 4-955-901-01 CUSHION (FL)
* 4-996-686-11 HOLDER (FL)
< CAPACITOR >
C751 1-162-290-31 CERAMIC 470PF 10% 50V
C752 1-162-290-31 CERAMIC 470PF 10% 50V
C753 1-164-159-11 CERAMIC 0.1uF 50V
C754 1-126-795-11 ELECT 10uF 20% 50V
C755 1-164-159-11 CERAMIC 0.1uF 50V
C756 1-162-290-31 CERAMIC 470PF 10% 50V
C757 1-162-290-31 CERAMIC 470PF 10% 50V
C758 1-162-290-31 CERAMIC 470PF 10% 50V
C759 1-162-306-11 CERAMIC 0.01uF 30% 16V
C760 1-162-213-31 CERAMIC 39PF 5% 50V
C761 1-126-795-11 ELECT 10uF 20% 50V
C762 1-126-795-11 ELECT 10uF 20% 50V
C792 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT US, Canadian)
< CONNECTOR >
CN701 1-779-556-11 CONNECTOR, FFC (LIF (NON-ZIF))19P
* CN702 1-691-670-11 CONNECTOR, BOARD TO BOARD 5P
< DIODE >
D751 8-719-046-44 LED SEL5221S-TP15 (CD SYNC NORMAL)
D752 8-719-046-44 LED SEL5221S-TP15 (CD SYNC HIGH)
< FLUORESCENT INDICATOR TUBE >
FL751 1-517-904-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC751 8-759-525-49 IC MSM9201-02GS-K
< TRANSISTOR >
Q751 8-729-900-80 TRANSISTOR UN4211-TA
Q752 8-729-900-80 TRANSISTOR UN4211-TA
Q753 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q754 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
R701 1-249-421-11 CARBON 2.2K 5% 1/4W
R702 1-247-843-11 CARBON 3.3K 5% 1/4W
R703 1-249-425-11 CARBON 4.7K 5% 1/4W
R704 1-249-429-11 CARBON 10K 5% 1/4W
R711 1-249-421-11 CARBON 2.2K 5% 1/4W
R712 1-247-843-11 CARBON 3.3K 5% 1/4W
R713 1-249-425-11 CARBON 4.7K 5% 1/4W
R714 1-249-429-11 CARBON 10K 5% 1/4W
R715 1-249-435-11 CARBON 33K 5% 1/4W
R721 1-249-421-11 CARBON 2.2K 5% 1/4W
R722 1-247-843-11 CARBON 3.3K 5% 1/4W
R723 1-249-425-11 CARBON 4.7K 5% 1/4W
R724 1-249-429-11 CARBON 10K 5% 1/4W
R725 1-249-435-11 CARBON 33K 5% 1/4W
R731 1-249-421-11 CARBON 2.2K 5% 1/4W
R732 1-247-843-11 CARBON 3.3K 5% 1/4W
R733 1-249-425-11 CARBON 4.7K 5% 1/4W
R734 1-249-429-11 CARBON 10K 5% 1/4W
R735 1-249-435-11 CARBON 33K 5% 1/4W
R741 1-249-421-11 CARBON 2.2K 5% 1/4W
R742 1-247-843-11 CARBON 3.3K 5% 1/4W
R743 1-249-425-11 CARBON 4.7K 5% 1/4W
R744 1-249-429-11 CARBON 10K 5% 1/4W
R745 1-249-435-11 CARBON 33K 5% 1/4W
R751 1-249-409-11 CARBON 220 5% 1/4W
R752 1-249-409-11 CARBON 220 5% 1/4W
R753 1-247-807-31 CARBON 100 5% 1/4W
R754 1-247-807-31 CARBON 100 5% 1/4W
R755 1-249-441-11 CARBON 100K 5% 1/4W
R756 1-249-441-11 CARBON 100K 5% 1/4W
R757 1-247-807-31 CARBON 100 5% 1/4W
R758 1-247-807-31 CARBON 100 5% 1/4W
R759 1-247-807-31 CARBON 100 5% 1/4W
R760 1-247-807-31 CARBON 100 5% 1/4W
R761 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S701 1-475-543-11 ENCODER, ROTARY
(l AMS L PUSH ENTER (CD))
S702 1-762-875-21 SWITCH, KEYBOARD (x CD))
S703 1-762-875-21 SWITCH, KEYBOARD (X (CD))
S704 1-762-875-21 SWITCH, KEYBOARD (H (CD))
S711 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE CD)
S712 1-762-875-21 SWITCH, KEYBOARD (TIME CD)
S713 1-762-875-21 SWITCH, KEYBOARD (CLEAR (CD))
S714 1-762-875-21 SWITCH, KEYBOARD (REC-IT (CD))
S715 1-762-875-21 SWITCH, KEYBOARD (M (CD))
S716 1-762-875-21 SWITCH, KEYBOARD (m (CD))
S721 1-475-543-11 ENCODER, ROTARY (l ANS L
PUSH ENTER (MD))
S722 1-762-875-21 SWITCH, KEYBOARD (CLEAR (CD))
S723 1-762-875-21 SWITCH, KEYBOARD (TIME MD)
S724 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE MD)
S725 1-762-875-21 SWITCH, KEYBOARD (INPUT)
S726 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S731 1-762-875-21 SWITCH, KEYBOARD (m (CD))
S732 1-762-875-21 SWITCH, KEYBOARD (YES)
S733 1-762-875-21 SWITCH, KEYBOARD (MENU/NO)
S734 1-762-875-21 SWITCH, KEYBOARD (CD SYNC HIGH)
S735 1-762-875-21 SWITCH, KEYBOARD (CD SYNC NORMAL)
S736 1-762-875-21 SWITCH, KEYBOARD (A OPEN/EJECT)
BD (MD) DISPLAY
