Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
83
S741 1-762-875-21 SWITCH, KEYBOARD (x (MD))
S742 1-762-875-21 SWITCH, KEYBOARD (X (MD))
S743 1-762-875-21 SWITCH, KEYBOARD (H (MD))
S744 1-762-875-21 SWITCH, KEYBOARD (M (MD))
S745 1-762-875-21 SWITCH, KEYBOARD (REC z (MD))
S746 1-762-875-21 SWITCH, KEYBOARD (A EJECT)
**************************************************************
1-674-748-11 HP BOARD
*********
< CAPACITOR >
C481 1-162-290-31 CERAMIC 470PF 10% 50V
C482 1-162-290-31 CERAMIC 470PF 10% 50V
C483 1-162-290-31 CERAMIC 470PF 10% 50V
(US, Canadian)
C483 1-164-159-11 CERAMIC 0.1uF 50V
(EXCEPT US, Canadian)
< JACK >
J481 1-770-306-11 JACK (LARGE TYPE) (PHONES) (BLACK)
J481 1-784-942-11 JACK (LARGE TYPE) (PHONES) (GOLD)
< FERRITE BEAD >
L481 1-410-397-21 FERRITE BEAD INDUCTOR
L482 1-410-397-21 FERRITE BEAD INDUCTOR
L483 1-410-397-21 FERRITE BEAD INDUCTOR
< RESISTOR >
R481 1-249-393-11 CARBON 10 5% 1/4W
R482 1-249-393-11 CARBON 10 5% 1/4W
< VARIABLE RESISTOR >
RV481 1-225-882-11 RES, VAR, CARBON 1K/1K (PHONE LEVEL)
**************************************************************
* 1-645-721-11 LOADING BOARD
**************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S151 1-572-086-11 SWITCH, LEAF (LOAD IN)
S152 1-572-086-11 SWITCH, LEAF (LOAD OUT)
**************************************************************
A-4724-860-A MAIN BOARD, COMPLETE
(EXCEPT US, Canadian)
A-4725-028-A MAIN BOARD, COMPLETE (US, Canadian)
*********************
* 4-941-237-11 HEAT SINK
7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT (B)
< BATTERY >
BT901 1-528-887-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR/RESISTOR/SHORT >
C201 1-136-356-11 FILM 470PF 5% 50V
C202 1-128-551-11 ELECT 22uF 20% 25V
C203 1-128-551-11 ELECT 22uF 20% 25V
C204 1-128-551-11 ELECT 22uF 20% 25V
C205 1-137-366-11 FILM 0.0022uF 5% 50V
C221 1-136-356-11 FILM 470PF 5% 50V
C222 1-128-551-11 ELECT 22uF 20% 25V
C223 1-137-368-11 FILM 0.0047uF 5% 50V
C224 1-130-471-00 MYLAR 0.001uF 5% 50V
C225 1-137-358-11 FILM 0.0001uF 5% 50V
C226 1-137-358-11 FILM 0.0001uF 5% 50V
C227 1-137-360-11 FILM 220PF 5% 50V
C228 1-128-551-11 ELECT 22uF 20% 25V
C251 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C301 1-136-356-11 FILM 470PF 5% 50V
C302 1-128-551-11 ELECT 22uF 20% 25V
C303 1-104-665-11 ELECT 100uF 20% 25V
C304 1-128-551-11 ELECT 22uF 20% 25V
C305 1-137-366-11 FILM 0.0022uF 5% 50V
C321 1-136-356-11 FILM 470PF 5% 50V
C322 1-128-551-11 ELECT 22uF 20% 25V
C323 1-137-368-11 FILM 0.0047uF 5% 50V
C324 1-130-471-00 MYLAR 0.001uF 5% 50V
C325 1-137-358-11 FILM 0.0001uF 5% 50V
C326 1-137-358-11 FILM 0.0001uF 5% 50V
C327 1-137-360-11 FILM 220PF 5% 50V
C328 1-104-665-11 ELECT 100uF 20% 25V
C401 1-104-665-11 ELECT 100uF 20% 25V
C402 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C403 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C404 1-126-933-11 ELECT 100uF 20% 16V
C405 1-126-934-11 ELECT 220uF 20% 10V
C406 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C407 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C408 1-126-933-11 ELECT 100uF 20% 16V
C409 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C415 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C416 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C417 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C418 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C419 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C420 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C421 1-126-934-11 ELECT 220uF 20% 10V
C422 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C423 1-126-933-11 ELECT 100uF 20% 16V
C452 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C453 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C501 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C502 1-126-933-11 ELECT 100uF 20% 16V
C503 1-126-960-11 ELECT 1uF 20% 50V
C504 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C505 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C506 1-163-234-11 CERAMIC CHIP 20PF 5% 50V
C507 1-126-933-11 ELECT 100uF 20% 16V
C510 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C511 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
DISPLAY HP LOADING MAIN
