– 5 –
• The equipment can be removed using the following procedure.
SECTION 3
DISASSEMBLY
5
cabinet (rear)
4
BVTP 3x10
3
BVTP 3x10
2
KTP 3x10
1
KTP 3x10
3-1. CABINET (REAR)
Set Cabinet (rear) Case (lower) section Cabinet (CD) section CD, Control board
Optical pick-up section
Tape mechanism deck section
Rear chassis (speaker) section Amplifier, terminal, jack board Power board
Note : Follow the disassembly procedure in the numerical order given.
