Sony PMC-D307L - Internal Component Disassembly

– 6 –
3-2. CASE (LOWER) SECTION
3-3. TAPE MECHANISM DECK SECTION
2 CN301, CNP302, 304, 306, 307
3 earth lead
4 BVTP 3x10
5 case (lower) section
1 parallel wire (27 core)
(CN303)
2 BVTP 3x10
3 BVTP 3x10
4 tape mechanism
deck section
1 P 2.6x8
