– 8 –
3-6. OPTICAL PICK-UP SECTION
3-7. REAR CHASSIS (SPEAKER) SECTION
1
screw (2.6x16)
2
optical pick-up section
3
CNP504
4
rear chassis (speaker) assy
1
B 3.5x16, tapping
2
B 3.5x16, tapping
