7. Remove the screw to detach the SW-1603 board.
P2 x 3
P2 x 3
Switch knobs (VF)
Switch knob (VF)
Harness
Harness
VR-351 board
Hole
CN100
CN100
CN100
Projection
SW-1603 board
Note
When installing the VR-351 board, fit the projection with the hole.
8. Install the removed parts by reversing the steps of removal.
PMW-300
2-15
