4. Remove the two screws (P2 x 5) to detach the VF insert cover assembly.
VF insert cover assembly
CMOS harness guide sheet
Front harness cover
P2 x 5
P2 x 5
P2 x 4
5. Remove the four screws to detach the front frame from the lens unit.
B2.6 x 5
B2.6 x 5
Front frame
Lens unit
6. Install the removed parts by reversing the steps of removal.
PMW-300
2-54
