Sony PMW-300 - Page 84

3. Remove the three screws to detach the CMOS harness holder.
CMOS harness holder
P2 x 4
4. Remove the four screws to detach the prism block assembly.
Prism block assembly
P2 x 5
P2 x 5
5. Install the removed parts by reversing the steps of removal.
PMW-300
2-56
