ID Diagnosis Error value Type1/2 Note
0x0d Version matching test (sub-micro-
computer of the rear panel)
-1: Error 1, 2 Normal end "0" is always re-
turned because there is no ap-
plicable device in this unit.
0x0e Version matching test (sub-micro-
computer of the outside panel)
-1: Error 1, 2 Normal end "0" is always re-
turned because there is no ap-
plicable device in this unit.
0x0f Version matching test (sub-micro-
computer of the viewfinder)
-1: Error 1, 2 Normal end "0" is always re-
turned because there is no ap-
plicable device in this unit.
Item6 (Power block diagnosis)
The power block diagnosis tests the following contents.
ID Diagnosis Error value Type1/2 Note
0x01 Power switch read -1: The power switch cannot be read. 1, 2 The power switch must
be set to ON.
-4: Diagnosis is disabled because the
power switch is not set to ON.
0x02 Battery recognition -1: Communication with battery is
disabled.
1, 2 An appropriate battery
must be connected.
-4: Diagnosis is disabled because no
battery is connected.
0x03 Power supply state -1: Power supply is not controlled
correctly.
1, 2 The power switch must
be set to ON.
-4: Diagnosis is disabled because the
power switch is not set to ON.
Item7 (Diagnosis between image processor and display block)
Diagnosis between the image processor and the display block tests the following content.
ID Diagnosis Error value Type1/2 Note
0x80 Video signal line test -1: Test pattern check error 1, 2 Video signal line test between
the camera signal processor IC
and the baseband processing IC.
Monitor output images will be
distorted during the test.
Item9 (Diagnosis between display block and media block)
Diagnosis between the display block and the media block tests the following contents.
ID Diagnosis Error value Type1/2 Note
0x91 Video signal line communication test
in playback direction
(Direction from MEDIA to DIS-
PLAY)
-1: Test pattern check error 1, 2 —
PMW-300
3-12
