Sony PVM-A250 - PWM Fan (Right)

1-7 (E)
PVM-A250
1-4-4. PWM Fan (Right)
. Remove the rear cover. (Refer to Section 1-4-1.)
. Remove the G2 board. (Refer to Section 1-4-3.)
Conductive cushion
3 Two screws
(PSW3 x 6)
CN7403
Upper side
Label
2 Harness
1 Clamper
5 Two screws
(BVTP3 x 8)
4 Fan bracket
6 PWM fan (right)
