3-9 (E)
PVM-A250
3-5. Abnormality Is Found in Control Operation
Are harnesses properly
connected?
No
Yes
Abnormality is found in control
operation.
*1
Refer to the Instruction Manual for
the parallel remote operation.
Connect the harnesses properly.
Are symptoms improved by
parallel remote
*1
operation?
No
Replace the H1 board.
(Refer to Section 1-4-6.)
Yes
Replace the OLED module
assembly.
(Refer to Section 1-4-9.)
To Next Page
