4-6
PVM-A250
Main Frame Block
BVTP3 x 8
BVTP3 x 8
BVTP
3 x 8
BVTP
3 x 8
B3 x 5
PSW3 x 6
PSW
3 x 6
PSW
3 x 6
PSW3 x 6
PSW3 x 6
PSW3 x 6
B
B
A
A
To H1 board
To Speaker
To H2 board
101
105
106
104
104
113
113
113
103
115
113
102
107
112
111
109
108
110
114
114
Serial No. 7000001 to 7001869: PVM-A250 (SY)
Serial No. 7200001 to 7200148: PVM-A250 (CN)
